STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
198
www.kyocera-sgstool.com
1B
•
1LB
•
1ELB
FRACTIONAL SERIES
inch
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
UNCOATED
W/FLAT
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Ti-NAMITE-A
(AlTiN)
W/FLAT
Di-NAMITE
®
(Diamond)
1/64 1/32 1-1/2 1/8 30102
–
39102
39002
30031
–
–
1B
1/32 5/64 1-1/2 1/8 30104
–
39104
39004
30032
–
–
1B
3/64 7/64 1-1/2 1/8 30106
–
39106
39006
30033
–
–
1B
1/16 3/16 1-1/2 1/8 30108
–
39108
39008
30034
–
91269 1B
5/64 3/16 1-1/2 1/8 30110
–
39110
39010
30035
–
–
1B
3/32 9/32 1-1/2 1/8 30112
–
39112
39012
30036
–
–
1B
7/64 3/8 1-1/2 1/8 30114
–
39114
39014
30037
–
–
1B
*1/8 3/8 1-1/2 1/8 30178
–
39178
39078
30069
–
–
1B
1/8 1/2 1-1/2 1/8 30116
–
39116
39016
30038
–
91273 1B
1/8 3/4 2-1/4 1/8 33142
–
31770
31780
31790
–
–
1LB
1/8 1
3 1/8 33144
–
31900
31918
31928
–
– 1ELB
9/64 1/2 2 3/16 30118
–
39118
39018
30039
–
–
1B
5/32 1/2 2 3/16 30120
–
39120
39020
30040
–
–
1B
11/64 5/8 2 3/16 30122
–
39122
39022
30041
–
–
1B
*3/16 5/8 2 3/16 30124
–
39124
39024
30042
–
–
1B
3/16 3/4 2-1/2 3/16 33102
–
31771
31781
31791
–
91277 1LB
3/16 1-1/8 3 3/16 33122
–
31902
31919
31929
–
– 1ELB
13/64 5/8 2-1/2 1/4 30126
–
39126
39026
30043
–
–
1B
7/32 5/8 2-1/2 1/4 30128
–
39128
39028
30044
–
–
1B
15/64 3/4 2-1/2 1/4 30130
–
39130
39030
30045
–
–
1B
*1/4 3/4 2-1/2 1/4 30132
–
39132
39032
30046
–
91281 1B
1/4 1-1/8 3 1/4 33104
–
31772
31782
31792
–
–
1LB
1/4 1-1/2 4 1/4 33124
–
31904
31920
31930
–
– 1ELB
17/64 3/4 2-1/2 5/16 30134
–
39134
39034
30047
–
–
1B
9/32 3/4 2-1/2 5/16 30136
–
39136
39036
30048
–
–
1B
19/64 13/16 2-1/2 5/16 30138
–
39138
39038
30049
–
1B
*5/16 13/16 2-1/2 5/16 30140
–
39140
39040
30050
–
91285 1B
5/16 1-1/8 3 5/16 33106
–
31773
31783
31793
–
–
1LB
5/16 1-5/8 4 5/16 33126
–
31906
31921
31931
–
– 1ELB
21/64 1 2-1/2 3/8 30142
–
39142
39042
30051
–
–
1B
continued on next page
FRACTIONAL
4 Flute Ball End
POS
4
For patent
information visit
www.ksptpatents.com
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0010
