P-SİSTEM DELİK TORNA KATERLERİ
P-SYSTEM BORING BARS
72 / 73
Takım Kodu
Ordering Code
Stok
Stock
Takım Ölçüleri (mm)
Dimension (mm)
Yedek Parçaları
Spare Parts
Kesici Uç
Insert
Altlık
Shim
Anahtar
Allen Key
Levye
Lever
Levye Vidası
Lever Screw
Altlık Yayı
Shim Spring
Baskı Parçası
Wedge Clamp
Baskı Vidası
Clamp Screw
95°
Sipariş Örneği/Ordering Example : 1 ad./pcs. S20R PWLNR 06
R: Sağ/Right L: Sol/Left Stokta/In Stock Stokta Yok/Non Stock Item
S20R PWLNR/L 06
S25S PWLNR/L 06
S32T PWLNR/L 06
S25S PWLNR/L 08C
S32T PWLNR/L 08C
S40U PWLNR/L 08C
S50V PWLNR/L 08C
A20P PWLNR/L 06
A25R PWLNR/L 06
A32S PWLNR/L 06
A25R PWLNR/L 08C
A32S PWLNR/L 08C
A40T PWLNR/L 08C
A50U PWLNR/L 08C
20
25
32
25
32
40
50
20
25
32
25
32
40
50
d h L f
D
min
18.3
23
30
23
30
37.5
47
18.3
23
30
23
30
37.5
47
200
250
300
250
300
350
400
170
200
250
200
250
300
350
13
17
22
17
22
27
35
13
17
22
17
22
27
22
≥
25
≥
32
≥
40
≥
32
≥
40
≥
50
≥
63
≥
25
≥
32
≥
40
≥
32
≥
40
≥
50
≥
63
R L
APL-01
APL-02
APL-01
APL-02
AAY-01
AAY-02
AAY-01
AAY-02
-
ACK-05
-
ACK-05
-
1515-M4x11
-
1515-M4x11
AAL-02-2.5
AAL-03-3
AAL-02-2.5
AAL-03-3
ALV-01-M6x14
ALV-02-M6x17
ALV-03-M8x19
ALV-01-M6x14
ALV-02-M6x17
ALV-03-M8x19
AAWN-SW317
AAWN-3-0001
AAWN-SW317
AAWN-3-0001
WNM. 0604..
WNM. 0804..
WNM. 0604..
WNM. 0804..
PWLNR
95°
d
