66MCR
METRIC SERIES
mm
NO. OF
FLUTES
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-X
6,0
19,0
63,0
6,0
0,5
7
46627
6,0
19,0
63,0
6,0
1,0
7
46628
8,0
20,0
63,0
8,0
0,5
7
46629
8,0
20,0
63,0
8,0
1,0
7
46630
8,0
20,0
63,0
8,0
1,5
7
46631
10,0
22,0
75,0
10,0
0,5
7
46632
10,0
22,0
75,0
10,0
1,0
7
46633
10,0
22,0
75,0
10,0
1,5
7
46634
10,0
22,0
75,0
10,0
2,0
7
46635
12,0
26,0
83,0
12,0
1,0
9
46636
12,0
26,0
83,0
12,0
1,5
9
46637
12,0
26,0
83,0
12,0
2,0
9
46638
12,0
26,0
83,0
12,0
2,5
9
46639
12,0
26,0
83,0
12,0
3,0
9
46640
16,0
32,0
92,0
16,0
1,0
9
46641
16,0
32,0
92,0
16,0
1,5
9
46642
16,0
32,0
92,0
16,0
2,0
9
46643
16,0
32,0
92,0
16,0
2,5
9
46644
16,0
32,0
92,0
16,0
3,0
9
46645
16,0
32,0
92,0
16,0
4,0
9
46646
continued on next page
METRIC
Multi-Carb
POS
7
9
11
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
• Heavy core and rigid
design allow for straight
walls
• High flute count design
results in smoother
cutting performance
and enhanced tool life
in precise finishing
applications
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
Neck Option Available
For patent
information visit
www.ksptpatents.com
