142 / 396
NON-FERROUS
PLASTICS/COMPOSITES
142
www.kyocera-sgstool.com
END MILLS
END MILLS
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/4
3/8
2
1/4
34916
34972
1/4
3/4
2-1/2
1/4
34917
34973
1/4
1
3
1/4
34918
34974
3/8
1/2
2
3/8
34919
34975
3/8
1
2-1/2
3/8
34920
34976
3/8
1-1/2
3-1/2
3/8
34921
34977
1/2
5/8
2-1/2
1/2
34922
34978
1/2
1
3
1/2
34923
34979
1/2
1-1/4
3
1/2
34924
34980
1/2
1-5/8
4
1/2
34925
34981
1/2
2
4
1/2
34926
34982
5/8
3/4
3
5/8
34927
34983
5/8
1-5/8
4
5/8
34928
34984
3/4
1
3
3/4
34929
34985
3/4
1-5/8
4
3/4
34930
34986
3/4
2-1/4
5
3/4
34931
34987
1
1-1/4
4
1
34932
34988
1
2
5
1
34933
34989
1
3-1/4
6
1
34934
34990
FRACTIONAL
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Open fluting for deep
slotting and profiling
• Ball nose design ideal for
finishing operations in
complex workpieces
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(inch)
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
BALL RADIUS
+0.0005/–0.0005
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
BALL RADIUS
+0.0005/–0.0005
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
BALL RADIUS
+0.0005/–0.0005
43B
FRACTIONAL SERIES
®
2
D
1
D
38°
L
1
L
2
For patent
information visit
www.ksptpatents.com
