138 / 396
NON-FERROUS
PLASTICS/COMPOSITES
138
www.kyocera-sgstool.com
END MILLS
END MILLS
43L
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/8
5/32
3
1/8
1/2
32700
32725
1/8
5/32
3
1/8
3/4
32691
34888
3/16
7/32
3
3/16
1/2
32701
32726
3/16
7/32
3
3/16
3/4
32692
34889
1/4
3/8
4
1/4
3/4
32702
32727
1/4
3/8
4
1/4
1-1/2
32703
32728
1/4
3/8
4
1/4
2-1/8
32704
32729
5/16
7/16
4
5/16
1-1/8
32705
32730
5/16
7/16
4
5/16
2-1/8
32706
32731
3/8
1/2
4
3/8
1-1/8
32707
32732
3/8
1/2
4
3/8
2-1/8
32708
32733
1/2
5/8
4
1/2
1-3/8
32709
32734
1/2
5/8
6
1/2
2-1/8
32710
32735
1/2
5/8
6
1/2
3-3/8
32711
32736
1/2
5/8
6
1/2
4-1/4
32697
34894
5/8
3/4
4
5/8
1-3/4
32712
32737
5/8
3/4
4
5/8
2-3/8
32713
32738
5/8
3/4
6
5/8
3-3/8
32714
32739
5/8
3/4
6
5/8
4-3/8
32698
34895
3/4
1
4
3/4
1-3/4
32715
32740
3/4
1
6
3/4
2-3/8
32716
32741
3/4
1
6
3/4
3-3/8
32717
32742
3/4
1
6
3/4
4-3/8
32699
34896
1
1-1/4
6
1
2-3/8
32718
32743
1
1-1/4
6
1
3-3/8
32719
32744
1
1-1/4
7
1
4-3/8
32720
32745
FRACTIONAL
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Symmetrical end gashing
for excellent balance
at high speeds and
aggressive plunging
capability
• Open fluting for deep
slotting and profiling
• Necked design with
blended diameter
transitions provide
clearance to reach
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(inch)
1/8–3/16
DIAMETER
D
1
=
+0.0000/–0.00032
D
2
=
h
6
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
®
For patent
information visit
www.ksptpatents.com
