Speed & Feed Recommendations listed after each series
Milling
SERIES
GENERAL PURPOSE END MILLS
DESCRIPTION PAGE
16 4 Flute Square End Stub Fractional 192
16M 4 Flute Square End Stub Metric 222
1 4 Flute Square End Standard Length Fractional 193
1L 4 Flute Square End Long Reach Fractional 193
1EL 4 Flute Square End Extended Length Fractional 193
1M 4 Flute Square End Standard Length Metric 223
1XLM 4 Flute Square End Extra Long Reach Metric 223
14 4 Flute Double End Square Stub Fractional 197
14M 4 Flute Double End Square Stub Metric 225
1B 4 Flute Ball End Standard Length Fractional 198
1LB 4 Flute Ball End Long Reach Fractional 198
1ELB 4 Flute Ball End Extended Length Fractional 198
1MB 4 Flute Ball End Standard Length Metric 226
1XLMB 4 Flute Ball End Extra Long Reach Metric 226
14B 4 Flute Double End Ball Stub Fractional 200
14MB 4 Flute Double End Ball Stub Metric 227
1CR 4 Flute Corner Radius Standard Length Fractional 195
1MCR 4 Flute Corner Radius Standard Length Metric 224
54 4 Flute High Shear Square End Standard Length Fractional 209
54M 4 Flute High Shear Square End Standard Length Metric 235
17 2 Flute Square End Stub Fractional 178
17M 2 Flute Square End Stub Metric 213
3 2 Flute Square End Standard Length Fractional 179
3L 2 Flute Square End Long Reach Fractional 179
3EL 2 Flute Square End Extended Length Fractional 179
3M 2 Flute Square End Standard Length Metric 214
3XLM 2 Flute Square End Extra Long Reach Metric 214
59 2 Flute Square End Long Reach Fractional 181
59M 2 Flute Square End Long Reach Metric 215
15 2 Flute Double End Square Stub Fractional 183
15M 2 Flute Double End Square Stub Metric 216
3B 2 Flute Ball End Standard Length Fractional 184
3LB 2 Flute Ball End Long Reach Fractional 184
3ELB 2 Flute Ball End Extended Length Fractional 184
3MB 2 Flute Ball End Standard Length Metric 217
3XLMB 2 Flute Ball End Extra Long Reach Metric 217
59B 2 Flute Ball End Long Reach Fractional 186
59MB 2 Flute Ball End Long Reach Metric 218
