END MILLS
END MILLS
44M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
W/FLAT
UNCOATED
Ti-NAMITE-B
(TiB
2
)
W/FLAT
Ti-NAMITE-B
(TiB
2
)
3,0
8,0
52,0
6,0
44505
49663
44506
49674
4,0
11,0
55,0
6,0
44509
49664
44510
49675
5,0
13,0
57,0
6,0
44513
49665
44514
49676
6,0
13,0
57,0
6,0
44517
49666
44518
49677
8,0
19,0
69,0
10,0
44521
49667
44522
49678
10,0
22,0
72,0
10,0
44525
49668
44526
49679
12,0
26,0
83,0
12,0
44529
49669
44530
49680
14,0
26,0
83,0
14,0
44533
49670
44534
49681
16,0
32,0
92,0
16,0
44537
49671
44538
49682
18,0
32,0
92,0
18,0
44541
49672
44542
49683
20,0
38,0
104,0
20,0
44545
49673
44546
49684
Contact your KSPT Sales Representative for more information on Corner Radius options.
METRIC
Ski-Carb
• Polished ski land
with primary and
secondary flute wall
design minimizes chip
interference by directing
chips away from
secondary flute
• Circular land allows for
increased control at
various speed and feed
rates ultimately reducing
chatter
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
2
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,000/–0,006
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,000/–0,008
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,000/–0,009
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,000/–0,011
D
2
=
h
6
>18–20
DIAMETER
D
1
=
+0,000/–0,013
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
