FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
SHANK
DIAMETER
D
2
MAXIMUM
REAM LENGTH
L
2
OVERALL
LENGTH
L
1
NO. OF
FLUTES
UNCOATED
3/64
3/64
3/4
1-1/2
4
70003
1/16
1/16
3/4
1-1/2
4
70004
5/64
5/64
1
2
4
70005
3/32
3/32
1-1/4
2-1/4
4
70006
7/64
7/64
1-1/4
2-1/4
4
70007
1/8
1/8
1-1/4
2-1/4
4
70008
9/64
9/64
1-1/2
2-1/2
4
70009
5/32
5/32
1-1/2
2-1/2
4
70010
11/64
11/64
1-3/4
2-3/4
4
70011
3/16
3/16
1-3/4
2-3/4
4
70012
13/64
13/64
2
3
4
70013
7/32
7/32
2
3
4
70014
15/64
15/64
2
3
4
70015
1/4
1/4
2
3
4
70016
17/64
17/64
2-1/4
3-1/4
6
70017
9/32
9/32
2-1/4
3-1/4
6
70018
19/64
19/64
2-1/4
3-1/4
6
70019
5/16
5/16
2-1/4
3-1/4
6
70020
21/64
21/64
2-3/8
3-1/2
6
70021
11/32
11/32
2-3/8
3-1/2
6
70022
23/64
23/64
2-3/8
3-1/2
6
70023
3/8
3/8
2-3/8
3-1/2
6
70024
25/64
25/64
2-7/8
4
6
70025
13/32
13/32
2-7/8
4
6
70026
27/64
27/64
2-7/8
4
6
70027
7/16
7/16
2-7/8
4
6
70028
29/64
29/64
2-7/8
4
6
70029
15/32
15/32
2-7/8
4
6
70030
31/64
31/64
2-7/8
4
6
70031
1/2
1/2
2-7/8
4
6
70032
FRACTIONAL
Straight Flute Accu-Reamer
4
6
TOLERANCES
(inch)
D
1
=
+.0002/–.0000
D
2
=
+.0002/–.0000
For patent
information visit
www.ksptpatents.com
