341 / 396
DRILLS
DRILLS
341
www.kyocera-sgstool.com
200
FRACTIONAL SERIES
inch
CUTTING
DIAMETER
D
1
SHANK
DIAMETER
D
2
MAXIMUM
REAM LENGTH
L
2
OVERALL
LENGTH
L
1
NO. OF
FLUTES
.0470 – .0625
1/16
3/4
1-1/2
4
.0626 – .0781
5/64
1
2
4
.0782 – .0938
3/32
1-1/4
2-1/4
4
.0939 – .1094
7/64
1-1/4
2-1/4
4
.1095 – .1250
1/8
1-1/4
2-1/4
4
.1251 – .1406
9/64
1-1/2
2-1/2
4
.1407 – .1562
5/32
1-1/2
2-1/2
4
.1563 – .1719
11/64
1-3/4
2-3/4
4
.1720 – .1875
3/16
1-3/4
2-3/4
4
.1876 – .2031
13/64
2
3
4
.2032 – .2188
7/32
2
3
4
.2189 – .2344
15/64
2
3
4
.2345 – .2500
1/4
2
3
4
.2501 – .2656
17/64
2-1/4
3-1/4
6
.2657 – .2812
9/32
2-1/4
3-1/4
6
.2813 – .2969
19/64
2-1/4
3-1/4
6
.2970 – .3125
5/16
2-1/4
3-1/4
6
.3126 – .3281
21/64
2-3/8
3-1/2
6
.3282 – .3438
11/32
2-3/8
3-1/2
6
.3439 – .3594
23/64
2-3/8
3-1/2
6
.3595 – .3750
3/8
2-3/8
3-1/2
6
.3751 – .3906
25/64
2-7/8
4
6
.3907 – .4062
13/32
2-7/8
4
6
.4063 – .4219
27/64
2-7/8
4
6
.4220 – .4375
7/16
2-7/8
4
6
.4376 – .4531
29/64
2-7/8
4
6
.4532 – .4688
15/32
2-7/8
4
6
.4689 – .4844
31/64
2-7/8
4
6
.4845 – .5000
1/2
2-7/8
4
6
FRACTIONAL
Straight Flute Accu-Reamer
TOLERANCES
(inch)
D
1
=
+.0002/–.0000
D
2
=
+.0002/–.0000
4
6
SER 200 Fractional reamers can be ordered to specific diameters according to the size range
of Cutting Diameter D
1
. Please order as:
• 200. Then the size of the cut diameter in fractional format.
• i.e. 200.0492
• Description: Series 200 size 0.0492
• For Metric sizes convert to fractional inches (i.e. ÷ 25.4)
• The above sample would be a 1.25mm size (1.25 ÷ 25.4 = 0.0492")
All other dimensions are fractional as per table including the Shank
