370 / 396
ROUTERS
ROUTERS
PLASTICS/COMPOSITES
370
www.kyocera-sgstool.com
21
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
1/8
1/2
2
1/4
90001
5/32
5/8
2-1/2
1/4
90005
3/16
3/4
2-1/2
1/4
90009
1/4
3/4
2-1/2
1/4
90013
1/4
1
2-1/2
1/4
90017
5/16
1
2-1/2
5/16
90021
5/16
1
3
1/2
90025
3/8
1
2-1/2
3/8
90029
3/8
1-1/4
3
1/2
90033
1/2
1-1/4
3
1/2
90037
1/2
1-1/2
3-1/2
1/2
90041
1/2
2
4
1/2
90045
5/8
2
4-1/2
5/8
90049
3/4
2
4-1/2
3/4
90053
FRACTIONAL
Up Cut
POS
RHC
2
TOLERANCES
(inch)
D
1
=
+.000/–.003
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
