112 / 396
HARDENEDSTEELS
112
www.kyocera-sgstool.com
END MILLS
END MILLS
57M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
6,0
13,0
89,0
6,0
46140
8,0
18,0
102,0
8,0
46141
10,0
22,0
102,0
10,0
46142
12,0
26,0
114,0
12,0
46143
16,0
32,0
140,0
16,0
46145
20,0
38,0
165,0
20,0
46147
Neck Option Available
METRIC
Power-Carb
NEG
6
TOLERANCES
(mm)
6
DIAMETER
D
1
=
+0,000/–0,030
D
2
=
h
6
8
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
10
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
12–20
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
• Ideal in Trochoidal
milling applications in
hardened steels and dry
machining
• Short flute length and
large core design to
reduce deflection
• Unsurpassed edge
strength with extreme
negative rake and
eccentric relief
• Recommended for
materials 45 to 65 HRc
(421 to 739 Bhn)
For patent
information visit
www.ksptpatents.com
