END MILLS
END MILLS
HARDENEDSTEELS
108
www.kyocera-sgstool.com
56MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
α
REACH
L
3
Ti-NAMITE-X
1,0
1,0
76,0
6,0
8°10'
2,0
91349
1,5
1,5
76,0
6,0
7°45'
3,0
91350
2,0
2,0
76,0
6,0
7°10'
4,0
91351
2,5
2,5
76,0
6,0
6°35'
5,0
91352
3,0
3,0
76,0
6,0
6°
6,0
91353
4,0
4,0
76,0
6,0
4°30'
8,0
91354
5,0
5,0
89,0
6,0
2°30'
10,0
91355
6,0
6,0
89,0
6,0
–
12,0
91356
8,0
8,0
102,0
8,0
–
16,0
91357
10,0
10,0
102,0
10,0
–
20,0
91358
12,0
12,0
114,0
12,0
–
24,0
91359
16,0
16,0
140,0
16,0
–
32,0
91360
20,0
20,0
165,0
20,0
–
40,0
91361
Neck Option Available
METRIC
Turbo-Carb
POS
2
TOLERANCES
(mm)
1–2,5
DIAMETER
D
1
=
+0,000/–0,025
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0013
>2,5–6
DIAMETER
D
1
=
+0,000/–0,030
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0015
>6–10
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0020
>10–20
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0025
• Short flute length and
rigid design to reduce
deflection
• S-Gash Ball geometry
minimizes load and
heat produced during
the cutting process,
ultimately enhancing
tool life
• Ideal for machining
complex contoured
shapes in hardened
steels
• Recommended for
materials 35 to 60 HRc
(327 to 654 Bhn)
For patent
information visit
www.ksptpatents.com
