END MILLS
END MILLS
www.kyocera-sgstool.com
Series
27M
Metric
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
6
8
10
12
16
N
CFRP, AFRP
(CARBON FIBER,
ARAMID FIBER)
Slot
1
≤ 1
120
RPM
6361
4771
3817
3181
2385
(96-164)
Fz
0.040
0.065
0.075
0.100
0.120
Feed (mm/min)
1018
1240
1145
1272
1145
Profile
≤ 0.5
≤ 1.5
150
RPM
7951
5963
4771
3976
2982
(120-180)
Fz
0.040
0.065
0.075
0.100
0.120
Feed (mm/min)
1272
1550
1431
1590
1431
HSM
≤ 0.5
≤ 2
250
RPM
13252
9939
7951
6626
4970
(200-300)
Fz
0.095
0.145
0.175
0.235
0.280
Feed (mm/min)
5036
5765
5566
6228
5566
GFRP
(FIBERGLASS)
Slot
1
≤ 1
100
RPM
5301
3976
3181
2650
1988
(80-120)
Fz
0.040
0.065
0.075
0.100
0.120
Feed (mm/min)
848
1034
954
1060
954
Profile
≤ 0.5
≤ 1.5
120
RPM
6361
4771
3817
3181
2385
(96-164)
Fz
0.040
0.065
0.075
0.100
0.120
Feed (mm/min)
1018
1240
1145
1272
1145
HSM
≤ 0.5
≤ 2
200
RPM
10602
7951
6361
5301
3976
(160-240)
Fz
0.095
0.145
0.175
0.235
0.280
Feed (mm/min)
4029
4612
4453
4983
4453
CARBON, GRAPHITE
Slot
1
≤ 1
145
RPM
7686
5765
4612
3843
2882
(116-174)
Fz
0.050
0.080
0.095
0.125
0.150
Feed (mm/min)
1537
1845
1752
1922
1729
Profile
≤ 0.5
≤ 1.5
185
RPM
9807
7355
5884
4903
3677
(148-222)
Fz
0.050
0.080
0.095
0.125
0.150
Feed (mm/min)
1961
2354
2236
2452
2206
HSM
≤ 0.5
≤ 2
300
RPM
15903
11927
9542
7951
5963
(240-360)
Fz
0.115
0.185
0.220
0.290
0.350
Feed (mm/min)
7315
8826
8397
9223
8349
PLASTICS
Slot
1
≤ 1
245
RPM
12987
9740
7792
6494
4870
(196-294)
Fz
0.050
0.080
0.095
0.125
0.150
Feed (mm/min)
2597
3117
2961
3247
2922
Profile
≤ 0.5
≤ 1.5
305
RPM
16168
12126
9701
8084
6063
(244-366)
Fz
0.050
0.080
0.095
0.125
0.150
Feed (mm/min)
3234
3880
3686
4042
3638
HSM
≤ 0.5
≤ 2
505
RPM
26769
20077
16062
13385
10038
(404-606)
Fz
0.115
0.185
0.220
0.290
0.350
Feed (mm/min)
12314
14857
14134
15526
14054
MACHINABLE
CERAMICS
MACHINABLE GLASS
Slot
1
≤ 1
10
RPM
530
398
318
265
199
(8-12)
Fz
0.020
0.035
0.045
0.050
0.060
Feed (mm/min)
42
56
57
53
48
Profile
≤ 0.5
≤ 1.5
15
RPM
795
596
477
398
298
(12-18)
Fz
0.020
0.035
0.045
0.050
0.060
Feed (mm/min)
64
83
86
80
72
HSM
≤ 0.5
≤ 2
25
RPM
1325
994
795
663
497
(20-30)
Fz
0.045
0.075
0.085
0.115
0.140
Feed (mm/min)
239
298
270
305
278
HSM (High Speed Machining)
rates shown are for use without coolant; rates may be increased with coolant
rpm = Vc x 3.82 / D
1
dust collection is vital when machining dry
ipm = Fz x 4 x rpm
diamond coating will increase tool life in graphite and composite materials
adjust parameters based on resin type and fiber structure
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information
reduce speed when overheating causes melting or damage to resin (www.kyocera-sgstool.com)
reduce feed if delamination or fraying occur
finish cuts typically required reduced feed and cutting depths
METRIC
Series 27
