END MILLS
END MILLS
www.kyocera-sgstool.com
NON-FERROUS
For patent
information visit
www.ksptpatents.com
43APR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-B
(TiB
2
)
3/4
1-3/8
4-1/4
3/4
2-3/8
.030
34000
3/4
1-3/8
4-1/4
3/4
2-3/8
.060
34001
3/4
1-3/8
4-1/4
3/4
2-3/8
.090
34002
3/4
1-3/8
4-1/4
3/4
2-3/8
.120
34003
3/4
1-1/4
4-7/8
3/4
3
.030
34004
3/4
1-1/4
4-7/8
3/4
3
.060
34005
3/4
1-1/4
4-7/8
3/4
3
.090
34006
3/4
1-1/4
4-7/8
3/4
3
.120
34007
1
1-3/4
4-1/2
1
2-1/2
.030
34008
1
1-3/4
4-1/2
1
2-1/2
.060
34009
1
1-3/4
4-1/2
1
2-1/2
.090
34010
1
1-3/4
4-1/2
1
2-1/2
.120
34011
1
1-1/2
5-1/4
1
3-1/4
.030
34012
1
1-1/2
5-1/4
1
3-1/4
.060
34013
1
1-1/2
5-1/4
1
3-1/4
.090
34014
1
1-1/2
5-1/4
1
3-1/4
.120
34015
Available on request: • JetStream Technology • Side exit coolant holes
FRACTIONAL
S-Carb APR
®
• Ultra high-productivity
rougher for Aluminum
alloys, specifically for
aircraft components
• Designed for machine
tools with capability
of 600 in³ per minute
material removal rates
• Symmetrical end
gashing for excellent
balance at high
speeds and aggressive
plunging capability
• Open fluting for deep
slotting and profiling
• Polished flutes
maximize chip
evacuation and provides
enhanced finish
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(inch)
3/4–1
DIAMETER
D
1
=
+0.00040/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0012
®
2
D
1
D
38°
R
L
1
L
2
L
3
