END MILLS
END MILLS
NON-FERROUS
PLASTICS/COMPOSITES
2
D
1
D
R
38°
L
1
L
2
POS
3
METRIC
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Symmetrical end
gashing for excellent
balance at high speeds
and aggressive plunging
capability
• Open fluting for deep
slotting and profiling
• Polished flutes
maximize chip
evacuation and provides
enhanced finish
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
43MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
POLISHED
FLUTE
Ti-NAMITE-B
(TiB
2
)
6,0
13,0
57,0
6,0
0,5
•
44902
6,0
13,0
57,0
6,0
1,0
•
44894
6,0
13,0
72,0
6,0
0,8
•
44842
6,0
13,0
72,0
6,0
1,2
•
44843
8,0
19,0
63,0
8,0
0,3
•
44846
8,0
19,0
63,0
8,0
0,5
•
44847
8,0
19,0
63,0
8,0
1,0
•
44848
8,0
19,0
63,0
8,0
1,5
•
44849
10,0
22,0
72,0
10,0
0,3
•
44854
10,0
22,0
72,0
10,0
0,5
•
44855
10,0
22,0
72,0
10,0
1,0
•
44856
10,0
22,0
72,0
10,0
1,5
•
44857
14,0
30,0
89,0
14,0
1,0
•
44868
14,0
30,0
89,0
14,0
2,0
•
44869
14,0
30,0
89,0
14,0
3,0
•
44870
16,0
32,0
92,0
16,0
4,0
•
44871
20,0
38,0
104,0
20,0
4,0
•
44879
TOLERANCES
(mm)
6
DIAMETER
D
1
=
+0,000/–0,008
D
2
=
h
6
R =
+0,00/–0,05
>6–10
DIAMETER
D
1
=
+0,000/–0,009
D
2
=
h
6
R =
+0,00/–0,05
>10–18
DIAMETER
D
1
=
+0,000/–0,011
D
2
=
h
6
R =
+0,00/–0,05
>18–20
DIAMETER
D
1
=
+0,000/–0,013
D
2
=
h
6
R =
+0,00/–0,05
For patent
information visit
www.ksptpatents.com
®
