43MLC
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
UNCOATED
Ti-NAMITE-B
(TiB
2
)
6,0
10,0
63,0
6,0
20,0
0,5
44769
44789
6,0
10,0
63,0
6,0
20,0
1,0
44770
44790
6,0
13,0
72,0
6,0
30,0
0,5
44771
44791
6,0
13,0
72,0
6,0
30,0
1,0
44772
44792
8,0
12,0
75,0
8,0
25,0
0,3
44773
44793
8,0
12,0
75,0
8,0
25,0
0,5
44774
44794
8,0
12,0
75,0
8,0
25,0
1,0
44775
44795
8,0
12,0
75,0
8,0
25,0
1,5
44776
44796
10,0
14,0
100,0
10,0
35,0
0,3
44777
44797
10,0
14,0
100,0
10,0
35,0
0,5
44778
44798
10,0
14,0
100,0
10,0
35,0
1,0
44779
44799
10,0
14,0
100,0
10,0
35,0
1,5
44780
44800
12,0
16,0
100,0
12,0
40,0
0,5
44781
44801
12,0
16,0
100,0
12,0
40,0
1,0
44782
44802
12,0
16,0
100,0
12,0
40,0
1,5
44783
44803
12,0
16,0
100,0
12,0
40,0
2,0
44784
44804
12,0
16,0
100,0
12,0
40,0
2,5
44832
44839
12,0
16,0
100,0
12,0
40,0
3,0
44833
44738
12,0
16,0
100,0
12,0
40,0
4,0
44834
44741
16,0
20,0
125,0
16,0
50,0
2,0
44785
44805
16,0
20,0
125,0
16,0
50,0
2,5
44835
44840
16,0
20,0
125,0
16,0
50,0
3,0
44836
44739
16,0
20,0
125,0
16,0
50,0
4,0
44786
44806
20,0
25,0
150,0
20,0
65,0
2,0
44787
44807
20,0
25,0
150,0
20,0
65,0
2,5
44837
44841
20,0
25,0
150,0
20,0
65,0
3,0
44838
44740
20,0
25,0
150,0
20,0
65,0
4,0
44788
44808
METRIC
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Symmetrical end gashing
for excellent balance
at high speeds and
aggressive plunging
capability
• Open fluting for deep
slotting and profiling
• Necked design with
blended diameter
transitions provide
clearance to reach
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
®
TOLERANCES
(mm)
>6–10
DIAMETER
D
1
=
+0,000/–0,009
D
2
=
h
6
R =
+0,00/–0,05
>10–18
DIAMETER
D
1
=
+0,000/–0,011
D
2
=
h
6
R =
+0,00/–0,05
>18–20
DIAMETER
D
1
=
+0,000/–0,013
D
2
=
h
6
R =
+0,00/–0,05
For patent
information visit
www.ksptpatents.com
2
D
R
1
D
38°
L
1
L
3
L
2
END MILLS
END MILLS
