DRILLS DRILLS 289
www.kyocera-sgstool.com
®
mm
Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D2
OVERALL
LENGTH
L1
FLUTE
LENGTH
L2
CLEARED
LENGTH
L 3
SHANK
LENGTH
L4
7/32 0.2188 5.56 1/4-32 6,0 95,0 57,0 48,0 36,0 51809
5,6 mm 0.2205 6,0 95,0 57,0 48,0 36,0 63601
5,7 mm 0.2244 6,0 95,0 57,0 48,0 36,0 63602
5,8 mm 0.2283 6,0 95,0 57,0 48,0 36,0 63603
5,9 mm 0.2323 6,0 95,0 57,0 48,0 36,0 63604
15/64 0.2344 5.95 6,0 95,0 57,0 48,0 36,0 51810
6,0 mm 0.2362 M7 X 1 6,0 95,0 57,0 48,0 36,0 63605
6,1 mm 0.2402 8,0 114,0 76,0 64,0 36,0 63606
6,2 mm 0.2441 M7 X 0,75 8,0 114,0 76,0 64,0 36,0 63607
6,3 mm 0.2480 8,0 114,0 76,0 64,0 36,0 63608
1/4 0.2500 6.35 8,0 114,0 76,0 64,0 36,0 51811
6,4 mm 0.2520 8,0 114,0 76,0 64,0 36,0 63609
6,5 mm 0.2559 8,0 114,0 76,0 64,0 36,0 63610
F 0.2570 6.53 5/16-18 8,0 114,0 76,0 64,0 36,0 51812
6,6 mm 0.2598 8,0 114,0 76,0 64,0 36,0 63611
6,7 mm 0.2638 8,0 114,0 76,0 64,0 36,0 63612
17/64 0.2656 6.75 5/16-20 8,0 114,0 76,0 64,0 36,0 51813
6,8 mm 0.2677 M8 X 1,25 8,0 114,0 76,0 64,0 36,0 63613
6,9 mm 0.2717 8,0 114,0 76,0 64,0 36,0 63614
7,0 mm 0.2756 M8 X 1 8,0 114,0 76,0 64,0 36,0 63615
7,1 mm 0.2795 8,0 114,0 76,0 64,0 36,0 63616
9/32 0.2812 7.14 5/16-32 8,0 114,0 76,0 64,0 36,0 51814
7,2 mm 0.2835 M8 X 0,75 8,0 114,0 76,0 64,0 36,0 63617
7,3 mm 0.2874 8,0 114,0 76,0 64,0 36,0 63618
7,4 mm 0.2913 8,0 114,0 76,0 64,0 36,0 63619
7,5 mm 0.2953 M8 X 0,5 8,0 114,0 76,0 64,0 36,0 63620
19/64 0.2969 7.54 8,0 114,0 76,0 64,0 36,0 51815
7,6 mm 0.2992 8,0 114,0 76,0 64,0 36,0 63621
7,7 mm 0.3031 8,0 114,0 76,0 64,0 36,0 63622
7,8 mm 0.3071 M9 X 1,25 8,0 114,0 76,0 64,0 36,0 63623
7,9 mm 0.3110 8,0 114,0 76,0 64,0 36,0 63624
5/16 0.3125 7.94 3/8-16 8,0 114,0 76,0 64,0 36,0 51816
8,0 mm 0.3150 M9 X 1 8,0 114,0 76,0 64,0 36,0 63625
8,1 mm 0.3189 10,0 142,0 95,0 80,0 40,0 63626
8,2 mm 0.3228 10,0 142,0 95,0 80,0 40,0 63627
8,3 mm 0.3268 10,0 142,0 95,0 80,0 40,0 63628
21/64 0.3281 8.33 3/8-20 10,0 142,0 95,0 80,0 40,0 51817
8,4 mm 0.3307 10,0 142,0 95,0 80,0 40,0 63629
Q 0.3320 8.43 3/8-24 10,0 142,0 95,0 80,0 40,0 51818
8,5 mm 0.3346 M10 X 1,5 10,0 142,0 95,0 80,0 40,0 63630
8,6 mm 0.3386 10,0 142,0 95,0 80,0 40,0 63631
8,7 mm 0.3425 10,0 142,0 95,0 80,0 40,0 63632
continued on next page
CONTINUED
140 8xD
FRACTIONAL & METRIC SERIES
FRACTIONAL & METRIC
ICe-Carb®
