DRILLS
DRILLS
291
www.kyocera-sgstool.com
®
mm
Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
11,2 mm 0.4409
12,0 162,0 114,0 96,0 45,0
63657
11,3 mm 0.4449
12,0 162,0 114,0 96,0 45,0
63658
11,4 mm 0.4488
12,0 162,0 114,0 96,0 45,0
63659
11,5 mm 0.4528
M12 X 0,5 12,0 162,0 114,0 96,0 45,0
63660
11,6 mm 0.4567
12,0 162,0 114,0 96,0 45,0
63661
11,7 mm 0.4606
12,0 162,0 114,0 96,0 45,0
63662
11,8 mm 0.4646
12,0 162,0 114,0 96,0 45,0
63663
11,9 mm 0.4685
12,0 162,0 114,0 96,0 45,0
63664
15/32 0.4688 11.91
1/2-28
12,0 162,0 114,0 96,0 45,0
51827
12,0 mm 0.4724
M14 X 2
12,0 162,0 114,0 96,0 45,0
63665
31/64 0.4844 12.30 9/16-12
14,0 178,0 133,0 112,0 45,0
51828
12,5 mm 0.4921
M14 X 1,5 14,0 178,0 133,0 112,0 45,0
63666
1/2 0.5000 12.70
14,0 178,0 133,0 112,0 45,0
51829
12,8 mm 0.5039
M14 X 1,25 14,0 178,0 133,0 112,0 45,0
63667
13,0 mm 0.5118
M14 X 1
14,0 178,0 133,0 112,0 45,0
63668
33/64 0.5156 13.10 9/16-18
14,0 178,0 133,0 112,0 45,0
51830
13,5 mm 0.5315
5/8-11
14,0 178,0 133,0 112,0 45,0
63669
13,8 mm 0.5433
14,0 178,0 133,0 112,0 45,0
63670
14,0 mm 0.5512
M16 X 2
14,0 178,0 133,0 112,0 45,0
63671
9/16 0.5625 14.29
16,0 203,0 152,0 128,0 48,0
51831
14,5 mm 0.5709
M16 X 1,5 16,0 203,0 152,0 128,0 48,0
63672
37/64 0.5781 14.68
5/8-18
16,0 203,0 152,0 128,0 48,0
51832
14,8 mm 0.5827
16,0 203,0 152,0 128,0 48,0
63673
15,0 mm 0.5906
M16 X 1
16,0 203,0 152,0 128,0 48,0
63674
15,5 mm 0.6102
M18 X 2,5 16,0 203,0 152,0 128,0 48,0
63675
15,8 mm 0.6220
16,0 203,0 152,0 128,0 48,0
63676
5/8 0.6250 15.88 11/16-16 16,0 203,0 152,0 128,0 48,0
51833
16,0 mm 0.6299
16,0 203,0 152,0 128,0 48,0
63677
21/32 0.6562 16.67
3/4-10
18,0 222,0 171,0 144,0 48,0
51834
11/16 0.6875 17.46
3/4-16
18,0 222,0 171,0 144,0 48,0
51835
3/4 0.7500 19.05 13/16-16 20,0 243,0 190,0 160,0 50,0
51836
CONTINUED
140 8xD
