306 / 396
DRILLS
DRILLS
306
www.kyocera-sgstool.com
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED
Ti-NAMITE-A
(AlTiN)
R
0.3390
8.61
4
2-1/2
2
51218
57194
8,7 mm 0.3425
125,0
81,0
64,0
61113
68355
11/32
0.3438
8.73
4
2-1/2
2
51122
57195
8,8 mm 0.3465
125,0
81,0
64,0
61114
68356
S
0.3480
8.84
4
2-1/2
2
51219
57196
8,9 mm 0.3504
125,0
81,0
64,0
61115
68357
9,0 mm 0.3543
125,0
81,0
64,0
61039
68287
T
0.3580
9.09
4-1/4
2-3/4 2-13/64
51220
57197
9,1 mm 0.3583
125,0
81,0
64,0
61116
68358
23/64
0.3594
9.13
4-1/4
2-3/4 2-13/64
51123
57198
9,2 mm 0.3622
125,0
81,0
64,0
61117
68359
9,3 mm 0.3661
125,0
81,0
64,0
61118
68360
U 0.3680
9.35
4-1/4
2-3/4 2-13/64
51221
57199
9,4 mm 0.3701
125,0
81,0
64,0
61119
68361
9,5 mm 0.3740
125,0
81,0
64,0
61041
68288
*3/8
0.3750
9.53
4-1/4
2-3/4 2-13/64
51124
57200
V
0.3770
9.58
4-1/4
2-3/4 2-13/64
51222
57201
9,6 mm 0.3780
133,0
87,0
69,0
61120
68362
9,7 mm 0.3819
133,0
87,0
69,0
61121
68363
9,8 mm 0.3858
133,0
87,0
69,0
61122
68364
W 0.3860
9.80
4-1/2
2-7/8 2-19/64
51223
57202
9,9 mm 0.3898
133,0
87,0
69,0
61123
68365
25/64
0.3906
9.92
4-1/2
2-7/8 2-19/64
51125
57203
10,0 mm 0.3937
133,0
87,0
69,0
61043
68289
X
0.3970
10.08
4-1/2
2-7/8 2-19/64
51224
57204
10,2 mm 0.4016
133,0
87,0
69,0
61124
68366
Y
0.4040
10.26
4-1/2
2-7/8 2-19/64
51225
57205
13/32
0.4062
10.32
4-1/2
2-7/8 2-19/64
51126
57206
Z
0.4130
10.49
4-1/2
2-7/8 2-19/64
51226
57207
10,5 mm 0.4134
133,0
87,0
69,0
61045
68290
27/64
0.4219
10.72
4-1/2
2-7/8 2-19/64
51127
57208
11,0 mm 0.4331
142,0
94,0
75,0
61047
68291
7/16
0.4375
11.11
4-1/2
2-7/8 2-19/64
51128
57209
11,5 mm 0.4528
142,0
94,0
75,0
61049
68292
29/64
0.4531
11.51
4-3/4
3
2-13/32
51129
57210
15/32
0.4688
11.91
4-3/4
3
2-13/32
51130
57211
12,0 mm 0.4724
151,0
101,0
80,0
61051
68293
31/64
0.4844
12.30
4-3/4
3
2-13/32
51131
57212
1/2
0.5000
12.70
4-3/4
3
2-13/32
51132
57213
*Series 101 Set
61175
57351
101
FRACTIONAL & METRIC SERIES
2
FRACTIONAL & METRIC
2 Flute Drills • Metric: DIN 338
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
TOLERANCES
(inch)
D
1
=
+.0000/–.0005
TOLERANCES
(mm)
D
1
=
+0,0000/–0,0127
For patent
information visit
www.ksptpatents.com
Pictured:
Series 101 Drill Set
