307 / 396
DRILLS
DRILLS
307
www.kyocera-sgstool.com
mm
EDP NO,
CUTTING
DIAMETER
D
1
/ D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED
Ti-NAMITE-A
(AlTiN)
0,5
20,0
3,0
–
62001
68643
0,55
21,0
3,5
–
62003
68644
0,6
21,0
3,5
–
62005
68645
0,65
22,0
4,0
–
62007
68646
0,7
23,0
4,5
–
62009
68647
0,75
23,0
4,5
–
62011
68648
0,8
24,0
5,0
–
62013
68649
0,85
24,0
5,0
–
62015
68650
0,9
25,0
5,5
4,0
62017
68651
0,95
25,0
5,5
4,0
62019
68652
1,0
26,0
6,0
4,7
62021
68653
1,05
26,0
6,0
4,7
62023
68654
1,1
28,0
7,0
5,4
62025
68655
1,15
28,0
7,0
5,4
62027
68656
1,2
30,0
8,0
6,0
62029
68657
1,25
30,0
8,0
6,0
62031
68658
1,3
30,0
8,0
6,0
62033
68659
1,35
32,0
9,0
7,0
62035
68660
1,4
32,0
9,0
7,0
62037
68661
1,45
32,0
9,0
7,0
62039
68662
1,5
32,0
9,0
7,0
62041
68663
1,6
34,0
10,0
7,0
62043
68664
1,7
34,0
10,0
7,0
62045
68665
1,8
36,0
11,0
8,0
62047
68666
1,9
36,0
11,0
8,0
62049
68667
2,0
38,0
12,0
9,0
62051
68668
2,1
38,0
12,0
9,0
62053
68669
2,2
40,0
13,0
10,0
62055
68670
2,3
40,0
13,0
10,0
62057
68671
2,4
43,0
14,0
11,0
62059
68672
2,5
43,0
14,0
11,0
62061
68673
2,6
43,0
14,0
11,0
62063
68674
2,7
46,0
16,0
12,0
62065
68675
2,8
46,0
16,0
12,0
62067
68676
continued on next page
METRIC
Short Length Self Centering Drills • DIN 6539
2
108M Plus
METRIC SERIES
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,000/–0,010
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,000/–0,012
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,000/–0,015
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,000/–0,018
D
2
=
h
6
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
For patent
information visit
www.ksptpatents.com
