mm
EDP NO,
CUTTING
DIAMETER
D
1
/ D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED
Ti-NAMITE-A
(AlTiN)
6,1
70,0
31,0
23,0
62133
68709
6,2
70,0
31,0
23,0
62135
68710
6,3
70,0
31,0
23,0
62137
68711
6,4
70,0
31,0
23,0
62139
68712
6,5
70,0
31,0
23,0
62141
68713
6,8
70,0
31,0
23,0
62142
68603
7,0
74,0
34,0
25,0
62143
68718
7,5
74,0
34,0
25,0
62145
68723
7,8
79,0
37,0
27,0
62146
68604
8,0
79,0
37,0
27,0
62147
68728
8,5
79,0
37,0
27,0
62149
68733
9,0
84,0
40,0
29,0
62151
68738
9,5
84,0
40,0
29,0
62153
68743
9,8
89,0
43,0
31,0
62154
68606
10,0
89,0
43,0
31,0
62155
68748
10,2
89,0
43,0
31,0
62156
68607
10,5
89,0
43,0
31,0
62066
68753
11,0
95,0
47,0
33,0
62157
68758
11,5
95,0
47,0
33,0
62084
68763
11,8
102,0
51,0
35,0
62158
68608
12,0
102,0
51,0
35,0
62159
68768
12,5
102,0
51,0
35,0
62102
68773
13,0
102,0
51,0
35,0
62112
68778
13,8
107,0
54,0
37,0
62164
68609
14,0
107,0
54,0
37,0
62116
68780
14,5
111,0
56,0
38,0
62166
68611
14,8
111,0
56,0
38,0
62167
68612
15,0
111,0
56,0
38,0
62168
68613
15,8
115,0
58,0
38,0
62170
68614
16,0
115,0
58,0
38,0
62171
68616
METRIC
Short Length Self Centering Drills • DIN 6539
108M Plus
METRIC SERIES
CONTINUED
