315 / 396
DRILLS
DRILLS
315
www.kyocera-sgstool.com
EDP NO.
CUTTING
DIAMETER
D
1
/ D
2
DECIMAL
EQUIV.
METRIC
EQUIV.
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED Ti-NAMITE-A
(AlTiN)
#33
0.1130
2.87
1-7/8
7/8
45/64
56033
56242
#32
0.1160
2.95
1-7/8
7/8
45/64
56032
56241
3,0 mm 0.1181
46,0
16,0
12,0
66009
66010
#31
0.1200
3.05
1-7/8
7/8
45/64
56031
56240
1/8
0.1250
3.18
1-7/8
7/8
45/64
56108
56140
#30
0.1285
3.26
1-15/16
15/16
3/4
56030
56239
#29
0.1360
3.45
1-15/16
15/16
3/4
56029
56238
3,5 mm 0.1378
52,0
20,0
15,0
66011
66012
#28
0.1405
3.57
1-15/16
15/16
3/4
56028
56237
9/64
0.1406
3.57
1-15/16
15/16
3/4
56109
56141
#27
0.1440
3.66
2-1/16
1
51/64
56027
56236
#26
0.1470
3.73
2-1/16
1
51/64
56026
56235
#25
0.1495
3.80
2-1/16
1
51/64
56025
56234
#24
0.1520
3.86
2-1/16
1
51/64
56024
56233
#23
0.1540
3.91
2-1/16
1
51/64
56023
56232
5/32
0.1562
3.97
2-1/16
1
51/64
56110
56142
#22
0.1570
3.99
2-1/8
1-1/16
55/64
56022
56231
4,0 mm 0.1575
55,0
22,0
17,0
66013
66014
#21
0.1590
4.04
2-1/8
1-1/16
55/64
56021
56230
#20
0.1610
4.09
2-1/8
1-1/16
55/64
56020
56229
#19
0.1660
4.22
2-1/8
1-1/16
55/64
56019
56228
#18
0.1695
4.31
2-1/8
1-1/16
55/64
56018
56227
11/64
0.1719
4.37
2-1/8
1-1/16
55/64
56111
56143
#17
0.1730
4.39
2-3/16
1-1/8
29/32
56017
56226
#16
0.1770
4.50
2-3/16
1-1/8
29/32
56016
56225
4,5 mm 0.1772
58,0
24,0
18,0
66015
66016
#15
0.1800
4.57
2-3/16
1-1/8
29/32
56015
56224
#14
0.1820
4.62
2-3/16
1-1/8
29/32
56014
56223
#13
0.1850
4.70
2-3/16
1-1/8
29/32
56013
56222
3/16
0.1875
4.76
2-3/16
1-1/8
29/32
56112
56144
#12
0.1890
4.80
2-3/16
1-1/8
29/32
56012
56221
#11
0.1910
4.85
2-3/16
1-1/8
29/32
56011
56220
#10
0.1935
4.91
2-3/16
1-1/8
29/32
56010
56219
#9
0.1960
4.98
2-1/4
1-3/16
61/64
56009
56218
5,0 mm 0.1969
62,0
26,0
20,0
66017
66018
#8
0.1990
5.05
2-1/4
1-3/16
61/64
56008
56217
#7
0.2010
5.11
2-1/4
1-3/16
61/64
56007
56216
13/64
0.2031
5.16
2-1/4
1-3/16
61/64
56113
56145
#6
0.2040
5.18
2-3/8
1-1/4
1
56006
56215
#5
0.2055
5.22
2-3/8
1-1/4
1
56005
56214
#4
0.2090
5.31
2-3/8
1-1/4
1
56004
56213
#3
0.2130
5.41
2-3/8
1-1/4
1
56003
56212
5,5 mm 0.2165
66,0
28,0
21,0
66019
66020
7/32
0.2188
5.56
2-3/8
1-1/4
1
56114
56146
#2
0.2210
5.61
2-7/16
1-5/16
1-3/64
56002
56211
#1
0.2280
5.79
2-7/16
1-5/16
1-3/64
56001
56210
continued on next page
FRACTIONAL & METRIC
Straight Flute Drills • Metric: DIN 6539
CONTINUED
106
FRACTIONAL & METRIC SERIES
