EDP NO.
CUTTING
DIAMETER
D
1
/ D
2
DECIMAL
EQUIV.
METRIC
EQUIV.
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED
Ti-NAMITE-A
(AlTiN)
#36
0.1065
2.71
2-1/4
1-1/4
1
53036
58011
7/64
0.1094
2.78
2-1/4
1-1/4
1
53107
58012
#35
0.1100
2.79
2-1/4
1-1/4
1
53035
58013
#34
0.1110
2.82
2-1/4
1-1/4
1
53034
58014
#33
0.1130
2.87
2-1/4
1-1/4
1
53033
58015
#32
0.1160
2.95
2-1/4
1-1/4
1
53032
58016
3,0 mm 0.1181
46,0
16,0
12,0
63000
68965
#31
0.1200
3.05
2-1/4
1-1/4
1
53031
58017
3,1 mm 0.1220
49,0
18,0
14,0
63044
68966
1/8
0.1250
3.18
2-1/4
1-1/4
1
53108
58018
3,2 mm 0.1260
49,0
18,0
14,0
63045
68967
#30
0.1285
3.26
2-1/4
1-1/4
1
53030
58019
3,3 mm 0.1299
49,0
18,0
14,0
63001
68968
3,4 mm 0.1339
52,0
20,0
15,0
63046
68969
#29
0.1360
3.45
2-1/2
1-3/8
1-7/64
53029
58020
3,5 mm 0.1378
52,0
20,0
15,0
63002
68970
#28
0.1405
3.57
2-1/2
1-3/8
1-7/64
53028
58021
9/64
0.1406
3.57
2-1/2
1-3/8
1-7/64
53109
58022
3,6 mm 0.1417
52,0
20,0
15,0
63047
68971
#27
0.1440
3.66
2-1/2
1-3/8
1-7/64
53027
58023
3,7 mm 0.1457
52,0
20,0
15,0
63003
68972
#26
0.1470
3.73
2-1/2
1-3/8
1-7/64
53026
58024
#25
0.1495
3.80
2-1/2
1-3/8
1-7/64
53025
58025
3,8 mm 0.1496
55,0
22,0
17,0
63048
68973
#24
0.1520
3.86
2-1/2
1-3/8
1-7/64
53024
58026
3,9 mm 0.1535
55,0
22,0
17,0
63049
68974
#23
0.1540
3.91
2-1/2
1-3/8
1-7/64
53023
58027
5/32
0.1562
3.97
2-1/2
1-3/8
1-7/64
53110
58028
#22
0.1570
3.99
2-1/2
1-3/8
1-7/64
53022
58029
4,0 mm 0.1575
55,0
22,0
17,0
63004
68975
#21
0.1590
4.04
2-1/2
1-3/8
1-7/64
53021
58030
#20
0.1610
4.09
2-1/2
1-3/8
1-7/64
53020
58031
4,1 mm 0.1614
55,0
22,0
17,0
63050
68976
4,2 mm 0.1654
55,0
22,0
17,0
63005
68977
#19
0.1660
4.22
2-3/4
1-5/8
1-19/64
53019
58032
4,3 mm 0.1693
58,0
24,0
18,0
63051
68978
#18
0.1695
4.31
2-3/4
1-5/8
1-19/64
53018
58033
11/64
0.1719
4.37
2-3/4
1-5/8
1-19/64
53111
58034
#17
0.1730
4.39
2-3/4
1-5/8
1-19/64
53017
58035
4,4 mm 0.1732
58,0
24,0
18,0
63052
68979
continued on next page
FRACTIONAL & METRIC
3 Flute Drills • Metric: DIN 6539
(mm)
(inch)
3
103
FRACTIONAL & METRIC SERIES
TOLERANCES
(inch)
D
1
=
+.0000/–.0005
D
2
=
h6
TOLERANCES
(mm)
D
1
=
+0,0000/–0,0127
D
2
=
h6
STEELS
CAST IRON
HARDENEDSTEELS
NON-FERROUS
