DRILLS
DRILLS
319
www.kyocera-sgstool.com
EDP NO.
CUTTING
DIAMETER
D
1
/ D
2
DECIMAL
EQUIV.
METRIC
EQUIV.
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
UNCOATED
Ti-NAMITE-A
(AlTiN)
#16
0.1770
4.50
2-3/4
1-5/8
1-19/64
53016
58036
4,5 mm 0.1772
58,0
24,0
18,0
63006
68980
#15
0.1800
4.57
2-3/4
1-5/18 1-19/64
53015
58037
4,6 mm 0.1811
58,0
24,0
18,0
63053
68981
#14
0.1820
4.62
2-3/4
1-5/8
1-19/64
53014
58038
#13
0.1850
4.70
2-3/4
1-5/8
1-19/64
53013
58039
4,7 mm 0.1850
58,0
24,0
18,0
63054
68982
3/16
0.1875
4.76
2-3/4
1-5/8
1-19/64
53112
58040
#12
0.1890
4.80
2-3/4
1-5/8
1-19/64
53012
58041
4,8 mm 0.1890
62,0
26,0
20,0
63055
68983
#11
0.1910
4.85
2-3/4
1-5/8
1-19/64
53011
58042
4,9 mm 0.1929
62,0
26,0
20,0
63056
68984
#10
0.1935
4.91
2-3/4
1-5/8
1-19/64
53010
58043
#9
0.1960
4.98
3
1-3/4
1-13/32
53009
58044
5,0 mm 0.1969
62,0
26,0
20,0
63007
68985
#8
0.1990
5.05
3
1-3/4
1-13/32
53008
58045
5,1 mm 0.2008
62,0
26,0
20,0
63057
68986
#7
0.2010
5.11
3
1-3/4
1-13/32
53007
58046
13/64
0.2031
5.16
3
1-3/4
1-13/32
53113
58047
#6
0.2040
5.18
3
1-3/4
1-13/32
53006
58048
5,2 mm 0.2047
62,0
26,0
20,0
63008
68987
#5
0.2055
5.22
3
1-3/4
1-13/32
53005
58049
5,3 mm 0.2087
62,0
26,0
20,0
63058
68988
#4
0.2090
5.31
3
1-3/4
1-13/32
53004
58050
5,4 mm 0.2126
66,0
28,0
21,0
63059
68989
#3
0.2130
5.41
3
1-3/4
1-13/32
53003
58051
5,5 mm 0.2165
66,0
28,0
21,0
63009
68990
7/32
0.2188
5.56
3
1-3/4
1-13/32
53114
58052
5,6 mm 0.2205
66,0
28,0
21,0
63060
68991
#2
0.2210
5.61
3
1-3/4
1-13/32
53002
58053
5,7 mm 0.2244
66,0
28,0
21,0
63061
68992
#1
0.2280
5.79
3
1-3/4
1-13/32
53001
58054
5,8 mm 0.2283
66,0
28,0
21,0
63062
68993
5,9 mm 0.2323
66,0
28,0
21,0
63063
68994
A
0.2340
5.94
3-1/4
2
1-39/64
53201
58055
15/64
0.2344
5.95
3-1/4
2
1-39/64
53115
58056
6,0 mm 0.2362
66,0
28,0
21,0
63010
68995
B
0.2380
6.05
3-1/4
2
1-39/64
53202
58057
6,1 mm 0.2402
70,0
31,0
23,0
63064
68996
C
0.2420
6.15
3-1/4
2
1-39/64
53203
58058
6,2 mm 0.2441
70,0
31,0
23,0
63011
68997
D
0.2460
6.25
3-1/4
2
1-39/64
53204
58059
6,3 mm 0.2480
70,0
31,0
23,0
63065
68998
1/4
0.2500
6.35
3-1/4
2
1-39/64
53116
58061
6,4 mm 0.2520
70,0
31,0
23,0
63066
68999
6,5 mm 0.2559
70,0
31,0
23,0
63012
69000
F
0.2570
6.53
3-1/4
2
1-39/64
53206
58062
6,6 mm 0.2598
70,0
31,0
23,0
63067
69001
G
0.2610
6.63
3-1/2
2-1/8
1-45/64
53207
58063
6,7 mm 0.2638
70,0
31,0
23,0
63068
69002
continued on next page
FRACTIONAL & METRIC
3 Flute Drills • Metric: DIN 6539
CONTINUED
103
FRACTIONAL & METRIC SERIES
