DRILLS
DRILLS
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
325
www.kyocera-sgstool.com
301M
METRIC SERIES
mm
EDP NO.
DRILL
DIAMETER
D
1
BODY
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
UNCOATED Ti-NAMITE-A
(AlTiN)
0,5
3,15
20,0
3,0
67005
67035
0,8
3,15
20,0
3,5
67007
67037
1
3,15
31,5
3,5
67009
67039
1,25
3,15
31,5
4,0
67011
67041
1,6
4,0
35,5
5,0
67013
67043
2
5,0
40,0
6,0
67015
67045
2,5
6,3
45,0
7,0
67017
67047
3,15
8,0
50,0
9,0
67019
67049
4
10,0
56,0
11,0
67021
67051
5
12,5
63,0
14,0
67023
67053
METRIC
Combined Drill & Countersink
2
TOLERANCES
(mm)
D
1
=
+0,076/–0,000
D
1
=
–0,0025/–0,0127
For patent
information visit
www.ksptpatents.com
