END MILLS
END MILLS
51MLC
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
TI-NAMITE-X
(TX)
6,0
8,0
75,0
6,0
32,0
0,5
45127
6,0
8,0
75,0
6,0
32,0
1,0
45187
6,0
8,0
75,0
6,0
32,0
1,5
45188
8,0
10,0
75,0
8,0
32,0
0,5
45128
8,0
10,0
75,0
8,0
32,0
1,0
45129
8,0
10,0
75,0
8,0
32,0
1,5
45189
8,0
10,0
75,0
8,0
32,0
2,0
45190
10,0
12,0
100,0
10,0
40,0
0,5
45191
10,0
12,0
100,0
10,0
40,0
1,0
45130
10,0
12,0
100,0
10,0
40,0
1,5
45131
10,0
12,0
100,0
10,0
40,0
2,0
45132
10,0
12,0
100,0
10,0
40,0
2,5
45192
12,0
15,0
100,0
12,0
48,0
0,5
45193
12,0
15,0
100,0
12,0
48,0
0,76
45194
12,0
15,0
100,0
12,0
48,0
1,0
45133
12,0
15,0
100,0
12,0
48,0
1,5
45134
12,0
15,0
100,0
12,0
48,0
2,0
45135
12,0
15,0
100,0
12,0
48,0
2,5
45195
12,0
15,0
100,0
12,0
48,0
3,0
45196
16,0
20,0
115,0
16,0
65,0
1,0
45136
16,0
20,0
115,0
16,0
65,0
1,5
45137
16,0
20,0
115,0
16,0
65,0
2,0
45138
16,0
20,0
115,0
16,0
65,0
2,5
45197
16,0
20,0
115,0
16,0
65,0
3,0
45198
16,0
20,0
115,0
16,0
65,0
4,0
45199
20,0
24,0
150,0
20,0
80,0
1,0
45139
20,0
24,0
150,0
20,0
80,0
1,5
45140
20,0
24,0
150,0
20,0
80,0
2,0
45141
20,0
24,0
150,0
20,0
80,0
2,5
45200
20,0
24,0
150,0
20,0
80,0
3,0
45201
20,0
24,0
150,0
20,0
80,0
4,0
45202
20,0
24,0
150,0
20,0
80,0
5,0
45203
≠
POS
6
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Necked design with
blended diameter
transitions provide
clearance to reach
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
METRIC
T-Carb
®
2
D
L
1
L
2
L
3
1
D
≠
41°
R
®
STEELS
STAINLESSSTEELS
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h6
R =
+0,000/–0,050
For patent
information visit
www.ksptpatents.com
