81 / 396
STEELS
STAINLESSSTEELS
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
81
www.kyocera-sgstool.com
END MILLS
END MILLS
51MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-X
(TX)
6,0
19,0
63,0
6,0
0,5
45112
6,0
19,0
63,0
6,0
1,0
45170
6,0
19,0
63,0
6,0
1,5
45171
8,0
20,0
63,0
8,0
0,5
45113
8,0
20,0
63,0
8,0
1,0
45114
8,0
20,0
63,0
8,0
1,2
45150
8,0
20,0
63,0
8,0
1,5
45172
8,0
20,0
63,0
8,0
2,0
45173
10,0
22,0
75,0
10,0
0,5
45174
10,0
22,0
75,0
10,0
1,0
45115
10,0
22,0
75,0
10,0
1,5
45116
10,0
22,0
75,0
10,0
2,0
45117
10,0
22,0
75,0
10,0
2,5
45175
12,0
26,0
83,0
12,0
0,5
45176
12,0
26,0
83,0
12,0
0,76
45177
12,0
26,0
83,0
12,0
1,0
45118
12,0
26,0
83,0
12,0
1,5
45119
12,0
26,0
83,0
12,0
2,0
45120
12,0
26,0
83,0
12,0
2,5
45178
12,0
26,0
83,0
12,0
3,0
45179
16,0
32,0
92,0
16,0
1,0
45121
16,0
32,0
92,0
16,0
1,5
45122
16,0
32,0
92,0
16,0
2,0
45123
16,0
32,0
92,0
16,0
2,5
45180
16,0
32,0
92,0
16,0
3,0
45181
16,0
32,0
92,0
16,0
4,0
45182
20,0
38,0
104,0
20,0
1,0
45124
20,0
38,0
104,0
20,0
1,5
45125
20,0
38,0
104,0
20,0
2,0
45126
20,0
38,0
104,0
20,0
2,5
45183
20,0
38,0
104,0
20,0
3,0
45184
20,0
38,0
104,0
20,0
4,0
45185
20,0
38,0
104,0
20,0
5,0
45186
≠
POS
6
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h6
R =
+0,000/–0,050
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
METRIC
T-Carb
®
2
D
L
1
L
2
1
D
≠
R
41°
®
For patent
information visit
www.ksptpatents.com
