END MILLS
END MILLS
STEELS
STAINLESSSTEELS
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
51ML
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
TI-NAMITE-X
(TX)
6,0
8,0
75,0
6,0
32,0
45106
8,0
10,0
75,0
8,0
32,0
45107
10,0
12,0
100,0
10,0
40,0
45108
12,0
15,0
100,0
12,0
48,0
45109
16,0
20,0
115,0
16,0
65,0
45110
20,0
24,0
150,0
20,0
80,0
45111
≠
POS
6
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h6
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Necked design with
blended diameter
transitions provide
clearance to reach
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
METRIC
T-Carb
®
2
D
L
1
L
2
L
3
1
D
≠
41°
®
For patent
information visit
www.ksptpatents.com
