103 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
103
END MILLS
END MILLS
www.kyocera-sgstool.com
7M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
3,0
25,0
75,0
3,0
70551
4,0
25,0
75,0
4,0
70552
5,0
25,0
75,0
5,0
70553
6,0
25,0
75,0
6,0
70554
8,0
25,0
75,0
8,0
70555
10,0
38,0
100,0
10,0
70556
12,0
50,0
100,0
12,0
70557
12,0
75,0
150,0
12,0
70558
14,0
75,0
150,0
14,0
70559
16,0
75,0
150,0
16,0
70560
18,0
75,0
150,0
18,0
70561
20,0
75,0
150,0
20,0
70562
25,0
75,0
150,0
25,0
70563
METRIC
Series 7
• Variable pitch allows
for improved chatter
suppression along with
improved surface finish
and enhanced tool life
• Raised land and
increased core diameter
designed to enhance
tool life and decrease
tool deflection
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
For patent
information visit
www.ksptpatents.com
TOLERANCES
(mm)
D
1
=
+0,000/+0,050
D
2
=
h
6
