STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
104
www.kyocera-sgstool.com
END MILLS
END MILLS
7MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
3,0
25,0
75,0
3,0
70527
4,0
25,0
75,0
4,0
70529
5,0
25,0
75,0
5,0
70531
6,0
25,0
75,0
6,0
70533
8,0
25,0
75,0
8,0
70535
10,0
38,0
100,0
10,0
70537
12,0
50,0
100,0
12,0
70539
12,0
75,0
150,0
12,0
70540
14,0
75,0
150,0
14,0
70542
16,0
75,0
150,0
16,0
70544
18,0
75,0
150,0
18,0
70546
20,0
75,0
150,0
20,0
70548
25,0
75,0
150,0
25,0
70550
METRIC
Series 7
• Variable pitch allows
for improved chatter
suppression along with
improved surface finish
and enhanced tool life
• Raised land and
increased core diameter
designed to enhance tool
life and decrease tool
deflection
• Ball nose design ideal for
finishing operations in
complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(mm)
D
1
=
+0,000/+0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
For patent
information visit
www.ksptpatents.com
