END MILLS
END MILLS
FRACTIONAL
S-Carb APF
®
Series
43APF
Fractional
Hardness
Ap
Ae
Ae
Vc
(sfm)
Diameter (D
1
)
(inch)
Ae x D
1
Ap x D
1
1/2
3/4
N
ALUMINUM ALLOYS
2024, 5052, 5086, 6061,
6063, 7075
≤ 150 Bhn
or
≤ 7 HRc
Profile
≤ 0.1
≤ 2.5
2625
RPM
20055
13370
(2100-3150)
Fz
0.0030
0.0050
Feed (in/min)
241
267
Profile
≤ 0.1
≤ 4
2625
RPM
20055
13370
(2100-3150)
Fz
0.0020
0.0040
Feed (in/min)
160
214
ALUMINUM ALLOYS
(LITHIUM)*
2090, 2091, 2099, 2195,
2199, 2297, 8090
≤ 150 Bhn
or
≤ 7 HRc
Profile
≤ 0.1
≤ 2.5
1970
RPM
15051
10034
(1576-2364)
Fz
0.0030
0.0050
Feed (in/min)
181
201
Profile
≤ 0.1
≤ 4
1970
RPM
15051
10034
(1576-2364)
Fz
0.0020
0.0040
Feed (in/min)
120
161
Bhn (Brinell) HRc (Rockwell C)
surface speed is dependent on machine spindle and fixturing
balancing is recommended at ultra high surface speeds
tool life may be reduced when machining Lithium Alloys
rpm = Vc x 3.82 / D
1
ipm = Fz x 4 x rpm
maximum recommended depths shown
reduce speed and feed for materials harder than listed
finish cuts typically require reduced feed and cutting depths of 0.02 X D
1
maximum
ramp angle = 6˚ (feed rate = 50%)
plunging not recommended
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information (www.kyocera-sgstool.com)
