END MILLS
END MILLS
NON-FERROUS
For patent
information visit
www.ksptpatents.com
43MAPR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-B
(TiB
2
)
12,0
18,0
83,0
12,0
38,0
–
44650
12,0
18,0
83,0
12,0
38,0
2,0
44685
12,0
18,0
83,0
12,0
38,0
3,0
44686
12,0
18,0
83,0
12,0
38,0
4,0
44687
16,0
24,0
92,0
16,0
51,0
–
44652
16,0
24,0
92,0
16,0
51,0
2,0
44688
16,0
24,0
92,0
16,0
51,0
3,0
44689
16,0
24,0
92,0
16,0
51,0
4,0
44690
20,0
30,0
86,0
20,0
45,0
–
44646
20,0
30,0
86,0
20,0
45,0
3,0
44647
20,0
30,0
86,0
20,0
45,0
4,0
44648
20,0
30,0
86,0
20,0
45,0
5,0
44649
20,0
35,0
104,0
20,0
64,0
–
44653
20,0
35,0
104,0
20,0
64,0
3,0
44691
20,0
35,0
104,0
20,0
64,0
4,0
44692
20,0
35,0
104,0
20,0
64,0
5,0
44693
25,0
35,0
108,0
25,0
55,0
3,0
44809
25,0
35,0
108,0
25,0
55,0
4,0
44810
25,0
35,0
108,0
25,0
55,0
5,0
44811
25,0
35,0
140,0
25,0
80,0
–
44654
25,0
35,0
140,0
25,0
80,0
3,0
44694
25,0
35,0
140,0
25,0
80,0
4,0
44695
25,0
35,0
140,0
25,0
80,0
5,0
44696
25,0
35,0
140,0
25,0
90,0
3,0
44645
Available on request: • JetStream Technology • Side exit coolant holes
METRIC
S-Carb APR
®
• Ultra high-productivity
rougher for Aluminum
alloys, specifically for
aircraft components
• Designed for machine
tools with capability
of 9.83 l³ per minute
material removal rates
• Symmetrical end
gashing for excellent
balance at high
speeds and aggressive
plunging capability
• Open fluting for deep
slotting and profiling
• Polished flutes
maximize chip
evacuation and provides
enhanced finish
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(mm)
12–25
DIAMETER
D
1
=
+0,010/–0,050
D
2
=
h
6
R =
+0,000/–0,030
®
2
D
1
D
38°
R
L
1
L
2
L
3
