43APF
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-B
(TiB
2
)
1/2
1-1/4
3-1/4
1/2
1-5/8
.030
34016
1/2
1-1/4
3-1/4
1/2
1-5/8
.060
34017
1/2
1-1/4
3-1/4
1/2
1-5/8
.090
34018
1/2
1-1/4
3-1/4
1/2
1-5/8
.120
34019
1/2
2
4
1/2
2-3/8
.030
34020
1/2
2
4
1/2
2-3/8
.060
34021
1/2
2
4
1/2
2-3/8
.090
34022
1/2
2
4
1/2
2-3/8
.120
34023
3/4
1-7/8
4-1/4
3/4
2-3/8
.030
34024
3/4
1-7/8
4-1/4
3/4
2-3/8
.060
34025
3/4
1-7/8
4-1/4
3/4
2-3/8
.090
34026
3/4
1-7/8
4-1/4
3/4
2-3/8
.120
34027
3/4
3
5-3/8
3/4
3-1/2
.030
34028
3/4
3
5-3/8
3/4
3-1/2
.060
34029
3/4
3
5-3/8
3/4
3-1/2
.090
34030
3/4
3
5-3/8
3/4
3-1/2
.120
34031
Available on request: • JetStream Technology
FRACTIONAL
S-Carb APF
®
• Ultra high-productivity
finisher for Aluminum
alloys, specifically for
aircraft components
• Two levels of chatter
suppression: variable
helix and indexing
• Designed for single
axial pass semi-
finishing and finishing
• Polished flutes
maximize chip
evacuation and provides
enhanced finish
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
≠
POS
4
TOLERANCES
(inch)
1/2–3/4
DIAMETER
D
1
=
+0.00040/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0012
®
2
D
1
D
R
L
1
L
2
L
3
38°
41°
