52M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE-C
(TiCN)
3,0
7,0
38,0
3,0
45277
49829
3,5
7,0
57,0
6,0
45279
49830
4,0
8,0
57,0
6,0
45281
49831
4,5
8,0
57,0
6,0
45283
49832
5,0
10,0
57,0
6,0
45285
49833
6,0
10,0
57,0
6,0
45287
49834
8,0
16,0
63,0
8,0
45289
49835
10,0
19,0
72,0
10,0
45291
49836
12,0
22,0
83,0
12,0
45293
49837
14,0
22,0
83,0
14,0
45295
49838
16,0
26,0
92,0
16,0
45297
49839
20,0
32,0
104,0
20,0
45299
49840
NON-FERROUS
PLASTICS/COMPOSITES
METRIC
2 Flute High Shear End Mills
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
2
