STEELS
CAST IRON
HARDENEDSTEELS
232
www.kyocera-sgstool.com
61M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
NO. OF
FLUTES
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
6,0
19,0 63,0
6,0
1,14
3
46107
46106
46110
8,0
19,0 63,0
8,0
1,14
3
46109
46108
46111
10,0 22,0 72,0 10,0 1,52
3
46113
46112
46114
12,0 26,0 83,0 12,0 1,52
4
46117
46116
46118
16,0 32,0 92,0 16,0 1,52
4
46121
46120
46122
20,0 38,0 104,0 20,0 1,52
4
46129
46128
46132
25,0 44,0 104,0 25,0 1,52
5
46131
46130
46133
METRIC
Single End Roughers (Coarse Pitch)
TOLERANCES
h10
(mm)
D
1
=
+0,000 / –0,100
D
2
=
h
6
R =
+0,127/–0,127
POS
3
4
5
For patent
information visit
