Series
52M, 54M
Metric
Hardness
Flutes
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
3
6
10
12
20
25
N
PLASTICS
ABS, Polycarbonate,
PVC, Polypropylene
Profile
488
RPM 51702 25851 15511 12926 7755
6204
(390-585)
Fz
0.0264 0.072 0.149 0.178 0.237 0.250
2
≤ 0.3
≤ 1.5
Feed
(mm/min)
2730
3723
4622
4601
3676
3102
4
≤ 0.3
≤ 1.5
5460
7445
9244
9203
7352
6204
Slot
390
RPM 41362 20681 12409 10340 6204
4963
(312-468)
Fz
0.0240 0.065 0.136 0.163 0.210 0.238
2
1
≤ 1
Feed
(mm/min)
1985
2689
3375
3371
2606
2363
4
1
≤ 0.25
3971
5377
6750
6742
5212
4725
PLASTICS
Fiberglass, Glass Filled
Profile
219
RPM 23266 11633 6980
5816
3490
2792
(176-263)
Fz
0.0197 0.053 0.109 0.132 0.173 0.190
2
≤ 0.3
≤ 1.5
Feed
(mm/min)
917
1233
1522
1536
1208
1061
4
≤ 0.3
≤ 1.5
1833
2466
3043
3071
2415
2122
Slot
175
RPM 18580 9290
5574
4645
2787
2230
(140-210)
Fz
0.0180 0.048 0.101 0.120 0.160 0.175
2
1
≤ 1
Feed
(mm/min)
669
892
1126
1115
892
780
4
1
≤ 0.25
1338
1784
2252
2230
1784
1561
Bhn (Brinell) HRc (Rockwell C) HRb (Rockwell B)
rpm = (Vc x 1000) / (D
1
x 3.14)
mm/min = Fz x number of flutes x rpm
reduce speed and feed for materials harder than listed
reduce feed and Ae when finish milling (.02 x D
1
maximum)
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information (www.kyocera-sgstool.com)
METRIC
2 Flute: High Shear End Mills
4 Flute: High Shear End Mills
