245 / 396
DRILLS
DRILLS
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
NON-FERROUS
HARDENEDSTEELS
245
www.kyocera-sgstool.com
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-A
(AlTiN)
EDP NO.
1/64 0.0156 0.40
1/8 1-1/2
1/8
5/64
1
51752*
1/32 0.0312 0.79
1/8 1-1/2
1/4
3/16
1
51269*
3/64 0.0469 1.19
1/16-64
1/8 1-1/2
3/8
5/16
1
51270*
1,25 mm 0.0492
3,0
38,0
9,5
8,0
25,0
64500*
1,45 mm 0.0571
3,0
38,0
9,5
8,0
25,0
64501*
#53 0.0595 1.51
1/8 1-1/2 3/8 5/16
1
64502*
1/16 0.0625 1.59
5/64-60
1/8
2
7/16
3/8
1-1/4
51271*
1,6 mm 0.0630
3,0
50,0
11,0
9,0
32,0
64503*
1,75 mm 0.0689
3,0
50,0
11,0
9,0
32,0
64504*
#50 0.0700 1.78
1/8
2
7/16 3/8 1-1/4
64505*
5/64 0.0781 1.98
1/8
2
1/2
7/16 1-1/4
51272*
#47 0.0785 1.99
1/8
2
1/2 7/16 1-1/4
64506*
2,05 mm 0.0807
3,0
50,0
12,0
11,0
32,0
64507*
#46 0.0810 2.06
1/8
2
1/2 7/16 1-1/4
64508*
#43 0.0890 2.26
1/8
2
1/2 7/16 1-1/4
64509*
#42 0.0935 2.37
1/8
2
1/2 7/16 1-1/4
64510*
3/32 0.0938 2.38
1/8-32
1/8
2
1/2
7/16 1-1/4
51273
#40 0.0980 2.49
1/8
2
9/16
1/2
1-1/4
51274
2,5 mm 0.0984
3,0
50,0
14,0
12,0
32,0
64511
#39 0.0995 2.53
1/8
2
9/16
1/2
1-1/4
51753
#38 0.1015 2.58
5-40
1/8
2
9/16
1/2
1-1/4
51754
#37 0.1040 2.64
5-44
1/8
2
9/16
1/2
1-1/4
51755
#36 0.1065 2.71
6-32
1/8
2
9/16
1/2
1-1/4
51756
7/64 0.1094 2.78
1/8
2
5/8
9/16 1-1/4
51275
#35 0.1100 2.79
1/8
2
5/8
9/16 1-1/4
51276
#34 0.1110 2.82
1/8
2
5/8
9/16 1-1/4
51277
#33 0.1130 2.87
6-40
1/8
2
5/8
9/16 1-1/4
51757
2,9 mm 0.1142
3,0
50,0
16,0
14,0
32,0
64512
#32 0.1160 2.95
1/8
2
5/8
9/16 1-1/4
51758
3,0 mm 0.1181
6,0
62,0
20,0
17,0
36,0
63155
#31 0.1200 3.05
1/8
2
5/8
9/16 1-1/4
51759
3,1 mm 0.1220
6,0
62,0
20,0
17,0
36,0
63741
1/8 0.1250 3.18
1/4 2-1/2
3/4 21/32 1-7/16
51330
3,2 mm 0.1260
M3,5 X 0,35
6,0
62,0
20,0
17,0
36,0
63156
#30 0.1285 3.26
1/4 2-1/2
3/4 21/32 1-7/16
51278
3,3 mm 0.1299
M4 X 0,7
6,0
62,0
20,0
17,0
36,0
63157
3,4 mm 0.1339
6,0
62,0
20,0
17,0
36,0
63158
#29 0.1360 3.45
8-32,8-36
1/4 2-1/2
3/4 21/32 1-7/16
51331
3,5 mm 0.1378
M4 X 0,5
6,0
62,0
20,0
17,0
36,0
63159
#28 0.1405 3.57
8-40
1/4 2-1/2
3/4 21/32 1-7/16
51760
9/64 0.1406 3.57
1/4 2-1/2
3/4 21/32 1-7/16
51332
3,6 mm 0.1417
M4 X 0,35
6,0
62,0
20,0
17,0
36,0
63160
#27 0.1440 3.66
1/4 2-1/2
3/4 21/32 1-7/16
51761
3,7 mm 0.1457
M4.5 X 0,75
6,0
62,0
20,0
17,0
36,0
63161
#26 0.1470 3.73
3/16-24
1/4 2-1/2
3/4 21/32 1-7/16
51762
#25 0.1495 3.80
10-24
1/4 2-5/8
7/8 23/32 1-7/16
51333
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
• Double margin design
improves accuracy and
surface finish along
with increased strength
for aggressive drilling
• Specialized self-
centering notched point
eliminates the need for
spot drilling decreasing
thrust and deflection
• Engineered edge
protection improves
edge strength and
reduces edge fatigue
allowing for increased
feed rates
• Recommended for
materials ≤ 56 HRc
(≤ 577 Bhn)
135 3xD
FRACTIONAL & METRIC SERIES
2
*Single Margin
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
>18–30
DIAMETER
D
1
=
+0,008/+0,029
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
