DRILLS DRILLS 249
www.kyocera-sgstool.com
CUTTING
DIAMETER
D1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D2
OVERALL
LENGTH
L1
FLUTE
LENGTH
L2
CLEARED
LENGTH
L3
SHANK
LENGTH
L4
Ti-NAMITE-A
(AlTiN)
EDP NO.
11,5 mm 0.4528 M12 X 0,5 12,0 102,0 55,0 45,0 45,0 63194
29/64 0.4531 11.51 1/2-20 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51360
11,6 mm 0.4567 12,0 102,0 55,0 45,0 45,0 63791
11,7 mm 0.4606 12,0 102,0 55,0 45,0 45,0 63792
11,8 mm 0.4646 12,0 102,0 55,0 45,0 45,0 63793
11,9 mm 0.4685 12,0 102,0 55,0 45,0 45,0 63794
15/32 0.4688 11.91 1/2-28 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51361
12,0 mm 0.4724 M14 X 2 12,0 102,0 55,0 45,0 45,0 63195
31/64 0.4844 12.30 9/16-12 1/2 4-1/4 2-5/16 1-7/8 1-49/64 51362
12,5 mm 0.4921 M14 X 1,5 14,0 107,0 60,0 49,0 45,0 63196
1/2 0.5000 12.70 1/2 4-1/4 2-5/16 1-7/8 1-49/64 51363
12,8 mm 0.5039 M14 X 1,25 14,0 107,0 60,0 49,0 45,0 63197
13,0 mm 0.5118 M14 X 1 14,0 107,0 60,0 49,0 45,0 63198
33/64 0.5156 13.10 9/16-18 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51364
17/32 0.5312 13.49 5/8-11 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51365
13,5 mm 0.5315 14,0 107,0 60,0 49,0 45,0 63199
35/64 0.5469 13.89 5/8-12 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51783
14,0 mm 0.5512 M16 X 2 14,0 107,0 60,0 49,0 45,0 63200
9/16 0.5625 14.29 5/8 4-9/16 2-1/2 2 1-57/64 51366
14,5 mm 0.5709 M16 X 1,5 16,0 115,0 65,0 51,0 48,0 63201
37/64 0.5781 14.68 5/8-18 5/8 4-9/16 2-1/2 2 1-57/64 51367
15,0 mm 0.5906 M16 X 1 16,0 115,0 65,0 51,0 48,0 63202
19/32 0.5938 15.08 11/16-11 5/8 4-9/16 2-1/2 2 1-57/64 51784
39/64 0.6094 15.48 11/16-12 5/8 4-9/16 2-1/2 2 1-57/64 51785
15,5 mm 0.6102 M18 X 2,5 16,0 115,0 65,0 51,0 48,0 63203
5/8 0.6250 15.88 11/16-16 5/8 4-9/16 2-1/2 2 1-57/64 51368
16,0 mm 0.6299 16,0 115,0 65,0 51,0 48,0 63204
41/64 0.6406 16.27 11/16-24 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51786
16,5 mm 0.6496 M18 X 1,5 18,0 123,0 73,0 58,0 48,0 63205
21/32 0.6562 16.67 3/4-10 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51369
17,0 mm 0.6693 18,0 123,0 73,0 58,0 48,0 63206
43/64 0.6719 17.07 3/4-12 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51787
11/16 0.6875 17.46 3/4-16 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51370
17,5 mm 0.6890 M20 X 2,5 18,0 123,0 73,0 58,0 48,0 63207
45/64 0.7031 17.86 3/4-20, 1/2-14 NPT 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51788
18,0 mm 0.7087 18,0 123,0 73,0 58,0 48,0 63208
23/32 0.7188 18.26 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51789
18,5 mm 0.7283 M20 X 1,5 20,0 131,0 79,0 63,0 50,0 63209
47/64 0.7344 18.65 13/16-12 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51790
19,0 mm 0.7480 20,0 131,0 79,0 63,0 50,0 63210
3/4 0.7500 19.05 13/16-16 3/4 5-1/4 3-1/16 2-7/16 1-31/32 51371
49/64 0.7656 19.45 7/8-9 7/8 5-1/4 3-1/16 2-7/16 1-31/32 51372
19,5 mm 0.7677 M22 X 2,5 20,0 131,0 79,0 63,0 50,0 63211
25/32 0.7812 19.84 7/8 6 3-11/16 2-11/16 2-1/8 51791
20,0 mm 0.7874 20,0 131,0 79,0 63,0 50,0 63212
51/64 0.7969 20.24 7/8-12 7/8 6 3-11/16 2-11/16 2-1/8 51792
20,5 mm 0.8071 22,0 150,0 93,0 73,0 53,0 64513
13/16 0.8125 20.64 7/8-14 7/8 6 3-11/16 2-11/16 2-1/8 51373
21,0 mm 0.8268 22,0 150,0 93,0 73,0 53,0 64514
22,0 mm 0.8661 22,0 150,0 93,0 73,0 53,0 64515
7/8 0.8750 22.23 15/16-16, 1-8 7/8 6 3-11/16 2-11/16 2-1/8 51374
59/64 0.9219 23.42 1-12 1 6 3-11/16 2-11/16 2-1/8 51375
FRACTIONAL & METRIC
Hi-PerCarb
135 3xD
FRACTIONAL & METRIC SERIES
CONTINUED
