248 / 396
DRILLS
DRILLS
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
NON-FERROUS
HARDENEDSTEELS
248
www.kyocera-sgstool.com
135 3xD
FRACTIONAL & METRIC SERIES
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-A
(AlTiN)
EDP NO.
8,6 mm 0.3386
10,0 89,0
47,0
40,0
40,0
63770
R 0.3390 8.61
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51615
8,7 mm 0.3425
10,0 89,0
47,0
40,0
40,0
63771
11/32 0.3438 8.73
3/8-32
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51352
8,8 mm 0.3465
M10 X 1,25 10,0 89,0
47,0
40,0
40,0
63184
S 0.3480 8.84
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51616
8,9 mm 0.3504
10,0 89,0
47,0
40,0
40,0
63772
9,0 mm 0.3543
M10 X 1
10,0 89,0
47,0
40,0
40,0
63185
T 0.3580 9.09
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51617
9,1 mm 0.3583
10,0 89,0
47,0
40,0
40,0
63773
23/64 0.3594 9.13
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51353
9,2 mm 0.3622
M10 X 0,75 10,0 89,0
47,0
40,0
40,0
63774
9,25 mm 0.3642 9.25
10,0 89,0
47,0
40,0
40,0
63186
9,3 mm 0.3661
10,0 89,0
47,0
40,0
40,0
63775
U 0.3680 9.35
7/16-14
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51354
9,4 mm 0.3701
10,0 89,0
47,0
40,0
40,0
63776
9,5 mm 0.3740
M10 X 0,5
10,0 89,0
47,0
40,0
40,0
63187
3/8 0.3750 9.53
3/8 3-1/2 1-27/32 1-37/64 1-9/16
51355
V 0.3770 9.58
1/2 3-1/2 1-27/32 1-37/64 1-9/16
51618
9,6 mm 0.3780
10,0 89,0
47,0
40,0
40,0
63777
9,7 mm 0.3819
10,0 89,0
47,0
40,0
40,0
63778
9,8 mm 0.3858
10,0 89,0
47,0
40,0
40,0
63779
W 0.3860
1/2 3-1/2 1-27/32 1-37/64 1-9/16
51619
9,9 mm 0.3898
10,0 89,0
47,0
40,0
40,0
63780
25/64 0.3906 9.92
7/16-20
1/2 3-1/2 1-27/32 1-37/64 1-9/16
51356
10,0 mm 0.3937
10,0 89,0
47,0
40,0
40,0
63188
X 0.3970 10.08
7/16-24
1/2 4-1/16 2-3/16 1-51/64 1-49/64
51620
10,1 mm 0.3976
12,0 102,0 55,0
45,0
45,0
63781
10,2 mm 0.4016
M12 X 1,75 12,0 102,0 55,0
45,0
45,0
63189
Y 0.4040 10.26
7/16-28
1/2 4-1/16 2-3/16 1-51/64 1-49/64
51621
10,3 mm 0.4055
12,0 102,0 55,0
45,0
45,0
63782
13/32 0.4062 10.32
1/2 4-1/16 2-3/16 1-51/64 1-49/64
51357
10,4 mm 0.4094
12,0 102,0 55,0
45,0
45,0
63783
Z 0.4130 10.49
1/2 4-1/16 2-3/16 1-51/64 1-49/64
51622
10,5 mm 0.4134
M12 X 1,5
12,0 102,0 55,0
45,0
45,0
63190
10,6 mm 0.4173
12,0 102,0 55,0
45,0
45,0
63784
10,7 mm 0.4213
12,0 102,0 55,0
45,0
45,0
63785
27/64 0.4219 10.72
1/2-13
1/2 4-1/16 2-3/16 1-51/64 1-49/64
51358
10,8 mm 0.4252
M12 X 1,25 12,0 102,0 55,0
45,0
45,0
63191
10,9 mm 0.4291
12,0 102,0 55,0
45,0
45,0
63786
11,0 mm 0.4331
M12 X 1
12,0 102,0 55,0
45,0
45,0
63192
11,1 mm 0.4370
12,0 102,0 55,0
45,0
45,0
63787
7/16 0.4375 11.11 1/4-18 NPT 1/2 4-1/16 2-3/16 1-51/64 1-49/64
51359
11,2 mm 0.4409
12,0 102,0 55,0
45,0
45,0
63788
11,25 mm 0.4429
12,0 102,0 55,0
45,0
45,0
63193
11,3 mm 0.4449
12,0 102,0 55,0
45,0
45,0
63789
11,4 mm 0.4488
12,0 102,0 55,0
45,0
45,0
63790
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
• Double margin design
improves accuracy and
surface finish along with
increased strength for
aggressive drilling
• Specialized self-
centering notched point
eliminates the need for
spot drilling decreasing
thrust and deflection
• Engineered edge
protection improves edge
strength and reduces
edge fatigue allowing for
increased feed rates
• Recommended for
materials ≤ 56 HRc
(≤ 577 Bhn)
2
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
>18–30
DIAMETER
D
1
=
+0,008/+0,029
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
