END MILLS
END MILLS
51LC
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
TI-NAMITE-X
(TX)
1/4
3/8
4
1/4
1-1/8
.015
35127
1/4
3/8
4
1/4
1-1/8
.030
35180
3/8
1/2
4
3/8
2-1/8
.015
35128
3/8
1/2
4
3/8
2-1/8
.030
35129
1/2
5/8
4
1/2
2-1/4
.015
35181
1/2
5/8
4
1/2
2-1/4
.030
35130
1/2
5/8
4
1/2
2-1/4
.060
35182
1/2
5/8
4
1/2
2-1/4
.090
35131
1/2
5/8
4
1/2
2-1/4
.120
35132
5/8
3/4
5
5/8
2-1/2
.015
35183
5/8
3/4
5
5/8
2-1/2
.030
35133
5/8
3/4
5
5/8
2-1/2
.060
35184
5/8
3/4
5
5/8
2-1/2
.090
35134
5/8
3/4
5
5/8
2-1/2
.120
35135
5/8
3/4
5
5/8
2-1/2
.190
35185
3/4
1
6
3/4
3-3/8
.030
35136
3/4
1
6
3/4
3-3/8
.060
35186
3/4
1
6
3/4
3-3/8
.090
35137
3/4
1
6
3/4
3-3/8
.120
35138
3/4
1
6
3/4
3-3/8
.190
35187
3/4
1
6
3/4
3-3/8
.250
35188
1
1-1/4
6
1
3-3/8
.030
35139
1
1-1/4
6
1
3-3/8
.060
35189
1
1-1/4
6
1
3-3/8
.090
35140
1
1-1/4
6
1
3-3/8
.120
35141
1
1-1/4
6
1
3-3/8
.190
35190
1
1-1/4
6
1
3-3/8
.250
35191
≠
POS
6
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h6
R =
+0.0000/–0.0020
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Necked design with
blended diameter
transitions provide
clearance to reach
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
FRACTIONAL
T-Carb
®
®
2
D
L
1
L
2
L
3
1
D
≠
41°
R
For patent
information visit
www.ksptpatents.com
