33MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-A
(AlTiN)
3,0
9,0
57,0
6,0
0,3
43445
3,0
9,0
57,0
6,0
0,5
43470
4,0
12,0
57,0
6,0
0,3
43446
4,0
12,0
57,0
6,0
0,5
43471
5,0
15,0
57,0
6,0
0,3
43447
5,0
15,0
57,0
6,0
0,5
43472
6,0
18,0
57,0
6,0
0,5
43448
6,0
18,0
57,0
6,0
1,0
43473
6,0
18,0
57,0
6,0
1,5
43474
6,0
18,0
57,0
6,0
2,0
43475
8,0
20,0
63,0
8,0
0,5
43449
8,0
20,0
63,0
8,0
1,0
43476
8,0
20,0
63,0
8,0
1,5
43477
8,0
20,0
63,0
8,0
2,0
43478
10,0
27,0
72,0
10,0
0,5
43450
10,0
27,0
72,0
10,0
1,0
43479
10,0
27,0
72,0
10,0
1,5
43480
10,0
27,0
72,0
10,0
2,0
43481
10,0
27,0
72,0
10,0
2,5
43482
12,0
30,0
83,0
12,0
0,5
43451
12,0
30,0
83,0
12,0
1,0
43483
12,0
30,0
83,0
12,0
1,5
43484
12,0
30,0
83,0
12,0
2,0
43485
12,0
30,0
83,0
12,0
2,5
43486
12,0
30,0
83,0
12,0
3,0
43487
12,0
30,0
83,0
12,0
4,0
43488
16,0
38,0
92,0
16,0
1,0
43452
16,0
38,0
92,0
16,0
1,5
43489
16,0
38,0
92,0
16,0
2,0
43490
16,0
38,0
92,0
16,0
2,5
43491
16,0
38,0
92,0
16,0
3,0
43492
16,0
38,0
92,0
16,0
4,0
43493
20,0
46,0
104,0
20,0
1,0
43453
20,0
46,0
104,0
20,0
2,0
43494
20,0
46,0
104,0
20,0
2,5
43495
20,0
46,0
104,0
20,0
3,0
43496
20,0
46,0
104,0
20,0
4,0
43497
METRIC
Series 33
• Specially engineered
step core design
provides stability for
aggressive ramping and
rigidity when flutes are
completely engaged
• Open design at axial
end accommodates
material flow and
load reduction during
machining operations
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
3
2
D
L
1
L
2
1
D
≠
R
32°-48°
TOLERANCES
(mm)
3–6
DIAMETER
D
1
=
+0,000/–0,030
D
2
=
h
6
R =
+0,000/–0,050
>6–10
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
R =
+0,000/–0,050
>10–20
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
For patent
information visit
www.ksptpatents.com
