100 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
100
www.kyocera-sgstool.com
END MILLS
END MILLS
7
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
1/8
3/4
2-1/4
1/8
70470
1/8
1
3
1/8
70471
3/16
3/4
2-1/2
3/16
70472
3/16
1-1/8
3
3/16
70473
1/4
1-1/8
3
1/4
70474
1/4
1-1/2
4
1/4
70475
5/16
1-1/8
3
5/16
70476
5/16
1-5/8
4
5/16
70477
3/8
1-1/8
3
3/8
70478
3/8
1-3/4
4
3/8
70479
7/16
2
4-1/2
7/16
70480
7/16
3
6
7/16
70481
1/2
2
4-1/2
1/2
70482
1/2
3
6
1/2
70483
5/8
2-1/4
5
5/8
70484
5/8
3
6
5/8
70485
3/4
2-1/4
5
3/4
70486
3/4
3
6
3/4
70487
1
2-1/4
5
1
70488
1
3
6
1
70489
FRACTIONAL
Series 7
• Variable pitch allows
for improved chatter
suppression along with
improved surface finish
and enhanced tool life
• Raised land and
increased core diameter
designed to enhance tool
life and decrease tool
deflection
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
