END MILLS
END MILLS
7B
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-X
1/8
3/4
2-1/4
1/8
70441
1/8
1
3
1/8
70442
3/16
3/4
2-1/2
3/16
70444
3/16
1-1/8
3
3/16
70445
1/4
1-1/8
3
1/4
70447
1/4
1-1/2
4
1/4
70448
5/16
1-1/8
3
5/16
70450
5/16
1-5/8
4
5/16
70451
3/8
1-1/8
3
3/8
70453
3/8
1-3/4
4
3/8
70454
7/16
2
4-1/2
7/16
70456
7/16
3
6
7/16
70457
1/2
2
4-1/2
1/2
70459
1/2
3
6
1/2
70460
5/8
2-1/4
5
5/8
70462
5/8
3
6
5/8
70463
3/4
2-1/4
5
3/4
70465
3/4
3
6
3/4
70466
1
2-1/4
5
1
70468
1
3
6
1
70469
FRACTIONAL
Series 7
• Variable pitch allows
for improved chatter
suppression along with
improved surface finish
and enhanced tool life
• Raised land and
increased core diameter
designed to enhance
tool life and decrease
tool deflection
• Ball nose design ideal
for finishing operations
in complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
4
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0010
For patent
information visit
www.ksptpatents.com
