FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
W/FLAT
Ti-NAMITE-B
(TiB
2
)
W/FLAT
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/4
3/4
2-7/16
3/8
34501
34502
32033
32053
1/4
1-1/4 3-1/16
3/8
34503
34504
32034
32054
1/4
1-3/4 3-9/16
3/8
34505
34506
32035
32055
5/16
1-3/8
3-1/8
3/8
34507
34508
32036
32056
3/8
3/4
2-1/2
3/8
34509
34510
32037
32057
3/8
1-1/2
3-1/4
3/8
34511
34512
32038
32058
3/8
2-1/2
4-1/4
3/8
34513
34514
32039
32059
1/2
1-1/4
3-1/4
1/2
34515
34516
32040
32060
1/2
2
4
1/2
34517
34518
32041
32061
1/2
3
5
1/2
34519
34520
32042
32062
5/8
1-5/8
3-3/4
5/8
34521
34522
32043
32063
5/8
2-1/2
4-5/8
5/8
34523
34524
32044
32064
3/4
1-5/8
3-7/8
3/4
34525
34526
32045
32065
3/4
3
5-1/4
3/4
34527
34528
32046
32066
3/4
4
6-1/4
3/4
34529
34530
32047
32067
1
2
4-1/2
1
34531
34532
32048
32068
1
4
6-1/2
1
34533
34534
32049
32069
Contact your KSPT Sales Representative for more information on Corner Radius options.
FRACTIONAL
Ski-Carb
• Polished ski land
with primary and
secondary flute wall
design minimizes chip
interference by directing
chips away from
secondary flute
• Circular land allows for
increased control at
various speed and feed
rates ultimately reducing
chatter
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
2
TOLERANCES
(inch)
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
