END MILLS
END MILLS
47ML
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
UNCOATED
Ti-NAMITE-B
(TiB
2
)
6,0
10,0
100,0
6,0
54,0
44561
44609
8,0
12,0
100,0
8,0
54,0
44562
44610
10,0
12,0
100,0
10,0
54,0
44563
44611
12,0
16,0
150,0
12,0
80,0
44564
44612
16,0
20,0
150,0
16,0
80,0
44565
44613
20,0
25,0
150,0
20,0
80,0
44566
44614
METRIC
S-Carb
®
POS
2
TOLERANCES
(mm)
6
DIAMETER
D
1
=
+0,000/–0,008
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,000/–0,009
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,000/–0,011
D
2
=
h
6
>18–20
DIAMETER
D
1
=
+0,000/–0,013
D
2
=
h
6
®
• Circular land reduces
edge aggressiveness
for varied speed and
feed rates
• 2 Flutes effectively
manage the large size
and volume of chips
produced during the
aggressive machining
process
• Excellent balance
at high speeds and
aggressive plunging
capability
• Necked design with
blended diameter
transitions provide
clearance to reach
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
For patent
information visit
www.ksptpatents.com
