STEELS
CAST IRON
HARDENEDSTEELS
206
www.kyocera-sgstool.com
61
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
NO. OF
FLUTES
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/4*
3/4
2-1/2
1/4
.045
3
36107
36106
36110
5/16* 3/4
2-1/2 5/16 .045
3
36109
36108
36111
3/8
7/8
2-1/2
3/8
.060
3
36113
36112
36114
1/2
1
3
1/2
.060
4
36117
36116
36118
5/8 1-1/4 3-1/2
5/8
.060
4
36121
36120
36122
3/4 1-5/8
4
3/4
.060
4
36125
36124
36126
1
1-3/4
4
1
.060
5
36129
36128
36130
*Without Flat
FRACTIONAL
Single End Roughers (Coarse Pitch)
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0040
D
2
=
h
6
R =
+0.0050/–0.0050
POS
3
4
5
