Ball End
FRACTIONAL SERIES
EDP NO.
DESCRIPTION
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Series 1B – 4 Flute, Single End
30190
39109
39090
30070
Series 3B – 2 Flute, Single End
30390
39390
39590
30600
Series 5B – 3 Flute, Single End
30590
30900
30944
31169
Series 14B – 4 Flute, Double End
31490
31482
39642
31217
Series 15B – 2 Flute, Double End
31590
31582
39692
31357
CUTTING
DIAMETER
D
1
SINGLE END
LENGTH OF CUT
L
2
DOUBLE END
LENGTH OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
1/8
1/2
1/4
1-1/2
1/8
3/16
5/8
3/8
2
3/16
1/4
3/4
1/2
2-1/2
1/4
5/16
13/16
1/2
2-1/2
5/16
3/8
1
9/16
2-1/2
3/8
1/2
1
5/8
3
1/2
FRACTIONAL
End Mills Sets
For patent
information visit
www.ksptpatents.com
Pictured:
Series 1 4 Flute Single
End Ball Endmill Set
