FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE-C
(TiCN)
1/16
3/16
1-1/2
1/8
35473
35500
3/32
3/8
1-1/2
1/8
35475
35501
1/8
7/16
1-1/2
1/8
35477
35502
5/32
9/16
2
3/16
35478
35503
3/16
9/16
2
3/16
35479
35504
7/32
5/8
2-1/2
1/4
35480
35505
1/4
3/4
2-1/2
1/4
35481
35506
9/32
3/4
2-1/2
5/16
35482
35507
5/16
13/16
2-1/2
5/16
35483
35508
3/8
7/8
2-1/2
3/8
35485
35509
7/16
1
2-3/4
7/16
35487
35510
1/2
1
3
1/2
35489
35511
9/16
1-1/8
3-1/2
9/16
35491
35512
5/8
1-1/4
3-1/2
5/8
35493
35513
3/4
1-1/2
4
3/4
35495
35514
1
1-1/2
4
1
35497
35515
FRACTIONAL
4 Flute High Shear End Mills
POS
4
TOLERANCES
(inch)
D1 =
+0.0000/–0.0020
D2 =
h
6
For patent
information visit
www.ksptpatents.com
