CUTTING
DIAMETER
D
1
SINGLE END
LENGTH OF CUT
L
2
DOUBLE END
LENGTH OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
1/8
1/2
1/4
1-1/2
1/8
3/16
5/8
3/8
2
3/16
1/4
3/4
1/2
2-1/2
1/4
5/16
13/16
1/2
2-1/2
5/16
3/8
1
9/16
2-1/2
3/8
1/2
1
5/8
3
1/2
Square End
FRACTIONAL SERIES
EDP NO.
DESCRIPTION
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Series 1 – 4 Flute, Single End
30189
39189
39089
30030
Series 3 – 2 Flute, Single End
30389
39389
39589
30470
Series 5 – 3 Flute, Single End
30589
39789
30810
30850
Series 14 – 4 Flute, Double End
31489
31481
39641
31190
Series 15 – 2 Flute, Double End
31589
31581
39691
31336
FRACTIONAL
End Mills Sets
For patent
information visit
www.ksptpatents.com
Pictured:
Series 1 4 Flute
Single End Square
Endmill Set
