227 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
227
www.kyocera-sgstool.com
14MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41406
48947
48968
48989
1,5
3,0
38,0
3,0
41410
48948
48969
48990
2,0
4,0
38,0
3,0
41414
48949
48970
48991
2,5
5,0
38,0
3,0
41418
48950
48971
48992
3,0
6,0
38,0
3,0
41422
48951
48972
48993
3,5
7,0
50,0
4,0
41426
48952
48973
48994
4,0
8,0
50,0
4,0
41430
48953
48974
48995
4,5
9,5
63,0
4,5
41434
48954
48975
48996
5,0
10,0
63,0
5,0
41438
48955
48976
48997
6,0
12,0
63,0
6,0
41442
48956
48977
48998
7,0
12,0
63,0
8,0
41446
48957
48978
48999
8,0
12,0
63,0
8,0
41450
48958
48979
49000
9,0
14,0
75,0
9,0
41454
48959
48980
49001
10,0
14,0
75,0
10,0
41458
48960
48981
49002
11,0
14,0
75,0
12,0
41462
48961
48982
49003
12,0
16,0
75,0
12,0
41466
48962
48983
49004
METRIC
4 Flute Double End Ball End
POS
4
For patent
information visit
www.ksptpatents.com
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
